參數資料
| 型號： | SKY72301-22 |
| 廠商： | Skyworks Solutions Inc |
| 文件頁數： | 1/22頁 |
| 文件大?。?/td> | 0K |
| 描述： | IC SYNTHESIZER 1GHZ 28-EPTSSOP |
| 產品目錄繪圖： | 28-TSSOP |
| 標準包裝： | 1 |
| 類型： | 分?jǐn)?shù) N 合成器 |
| PLL： | 是 |
| 輸入： | 時鐘，晶體 |
| 輸出： | 時鐘，晶體 |
| 電路數： | 1 |
| 比率 - 輸入:輸出： | 2:2 |
| 差分 - 輸入:輸出： | 是/是 |
| 頻率 - 最大： | 1GHz |
| 除法器/乘法器： | 是/無 |
| 電源電壓： | 2.7 V ~ 3.3 V |
| 工作溫度： | -40°C ~ 85°C |
| 安裝類型： | 表面貼裝 |
| 封裝/外殼： | 28-SOIC（0.173"，4.40mm 寬）裸露焊盤 |
| 供應商設備封裝： | 28-TSSOP 裸露焊盤 |
| 包裝： | 標準包裝 |
| 產品目錄頁面： | 587 (CN2011-ZH PDF) |
| 其它名稱： | 863-1078-6 |
DATA SHEET
SKY72301-22: Spur-Free, 1.0 GHz Dual Fractional-N
Frequency Synthesizer
Applications
General purpose RF systems
Low bit rate wireless telemetry
Instrumentation
Specialized Mobile Radios (SMRs) and Private Mobile Radios
(PMRs)
Features
Spur-free operation
1.0 GHz maximum operating frequency
500 MHz maximum auxiliary synthesizer
Ultra-small step size, 100 Hz or less
High internal reference frequency enables large loop bandwidth
implementations
Very fast switching speed (e.g., below 100 s)
Phase noise to –96 dBc/Hz inside the loop filter bandwidth
@ 950 MHz
Software programmable power-down modes
High-speed serial interface up to 100 Mbps
Three-wire programming
Programmable division ratios on reference frequency
Phase detectors with programmable gain provide a
programmable loop bandwidth
Frequency power steering further enhances rapid acquistion
time
On-chip crystal oscillator
Frequency adjust for temperature compensation
Direct digital modulation
3 V operation
Skyworks offers lead (Pb)-free, RoHS (Restriction of
Hazardous Substances) compliant packaging.
5 V output to loop filter
EP-TSSOP (28-pin, 9.7 x 6.4 x 1.1 mm) package (MSL3, 260 C
per JEDEC J-STD-020)
Description
Skyworks SKY72301-22 direct digital modulation fractional-N
frequency synthesizer provides ultra-fine frequency resolution,
fast switching speed, and low phase-noise performance. This
synthesizer is a key building block for high-performance radio
system designs that require low power and fine step size.
The ultra-fine step size of less than 100 Hz allows this synthesizer
to be used in very narrowband wireless applications. With proper
temperature sensing or through control channels, the
synthesizer’s fine step size can compensate for crystal oscillator
or Intermediate Frequency (IF) filter drift. As a result, crystal
oscillators or crystals can replace temperature- compensated or
ovenized crystal oscillators, reducing parts count and associated
component cost. The device’s fine step size can also be used for
Doppler shift corrections.
The SKY72301-22 has a phase noise floor of –95 dBc/Hz up to
1.0 GHz operation as measured inside the loop bandwidth. This is
permitted by the on-chip low noise dividers and low divide ratios
provided by the device’s high fractionality.
Reference crystals or oscillators up to 50 MHz can be used with
the SKY72301-22. The crystal frequency is divided down by
independent programmable divider ratios of 1 to 32 for the main
and auxiliary synthesizers. The phase detectors can operate at a
maximum speed of 25 MHz, which allows better phase noise due
to the lower division value. With a high reference frequency, the
loop bandwidths can also be increased. Larger loop bandwidths
improve the settling times and reduce in-band phase noise.
Therefore, typical switching times of less than 100 s can be
achieved. The lower in-band phase noise also permits the use of
lower cost Voltage Controlled Oscillators (VCOs) in customer
applications.
The SKY72301-22 has a frequency power steering circuit that
helps the loop filter steer the VCO when the frequency is too fast
or too slow, further enhancing acquisition time.
Skyworks Solutions, Inc. Phone [781] 376-3000 Fax [781] 376-3100 sales@skyworksinc.com www.skyworksinc.com
200706C Skyworks Proprietary Information Products and Product Information are Subject to Change Without Notice September 11, 2009
1
