Pin Descriptions
(Continued)
Pin Number
Name
Type
Description
G5, G8, G9, H5, H6, H8, H9,
J5, J6, J7, J9, J10
NC (1:12)
No connect.
C1, D1
D2, D3
PGND
PVDD
PLL ground.
PLL power supply.
Individual Powerdown. PWDN (0:7) driven low puts individual
serializers into TRI-STATE, low power ’sleep’ mode. Default at
Low.
SYNC pattern enable. When driven high for a mininum of 4
cycles, SYNC patterns will be transmitted on the Bus LVDS
serial output. The SYNC pattern sent by the serializer consists
of six ones and six zeros switching at the input clock rate.
SYNC pattern continues to be sent if SYNC continues at high.
Default at Low. See
Functional Description
.
Test Clock Input to support IEEE 1149.1
Test Data Input to support IEEE 1149.1. There is an internal
pullup resistor that defaults this input to high per IEEE 1149.1.
Test Data Output to support IEEE 1149.1
Test Mode Select Input to support IEEE 1149.1. There is an
internal pullup resistor that defaults this input to high per IEEE
1149.1.
Test Reset Input to support IEEE 1149.1. There is an internal
pullup resistor that defaults this input to high per IEEE 1149.1.
N1, N2, N13, M1, M2, M12,
P13, P14
PWDN (0:7)
3.3 V
CMOS
I
J8, K5, K7, K8, K9, L1, L2,
N12
SYNC (0:7)
3.3 V
CMOS
I
C13
TCK
B14
TDI
C14
TDO
A14
TMS
C12
TRSTN
F14
TCLK
3.3 V
CMOS
I
Transmit Clock. Input for 25MHz - 66 MHz (nominal) system
clock.
S
www.national.com
17
