參數資料
| 型號： | SCAN928028TUF |
| 廠商： | NATIONAL SEMICONDUCTOR CORP |
| 元件分類： | 通用總線功能 |
| 英文描述： | 8 Channel 10:1 Serializer with IEEE 1149.1 and At-Speed BIST |
| 中文描述： | OCTAL LINE DRIVER, PBGA196 |
| 封裝： | LBGA-196 |
| 文件頁數： | 16/18頁 |
| 文件大小： | 376K |
| 代理商： | SCAN928028TUF |
Pin Descriptions
Pin Number
C7, C9, C10, D6, D7, D9,
Name
Type
Description
E5, E7, G7
AGND
Analog ground.
C6, C8, C11, D5, D8, D10,
E6, E8, F7
AVDD
Analog power supply.
B12
BIST_ACT
3.3 V
CMOS
I
3.3 V
CMOS
I
3.3 V
CMOS
I
BIST Active. Control pin for BIST mode enable.When
BIST_ACT = H and BIST_SEL (0:3) = 0H to 8H, device will go
to BIST mode accordingly. See
Table 1
Default at Low
A13, B13, D11, E11
BIST_SEL
(0:3)
BIST select. Control pins for which serializer is set for BIST
mode. See
Table 1
(Note 4)
M14
DEN
Serializer output data enable. Enable data output DOUTn (0:9).
n = serializer number. When driven low, puts the Bus LVDS
outputs in TRI-STATE. Default at Low.
A2, A3, A12, B2, B3, C2, C4,
D12, E1, E2, E9, E10, E12,
E13, E14, F6, F10, H10, K6,
K10, M13, P1
DGND
Digital Ground.
E3, E4, F1, F2, F3, F4, F11,
F12, G1, G2, G3, G4, G11,
G12, G14, H1, H2, H3, H4,
H11, H12, H13, H14, J1, J2,
J3, J4, J11, J12, J13, J14,
K1, K2, K3, K4, K11, K12,
K13, K14, L3, L4, L5, L6, L7,
L8, L9, L10, L11, L12, L13,
L14, M3, M4, M5, M6, M7,
M8, M9, M10, M11, N3, N4,
N5, N6, N7, N8, N9, N10,
N11, P2, P3, P4, P5, P6, P7,
P8, P9, P10 P11, P12
B11-A11, B10-A10, B9-A9,
B8-A8, B7-A7, A6-B6,
DINnx
3.3 V
CMOS
I
Data input. Inputs for the ten bit serializers. n = serializer
number, x = bit number. Default at Low.
A5-B5, A4-B4
Doutn
±
Bus LVDS
O
Bus LVDS differential outputs. n = serializer number.
A1, B1, C3, C5, D4, D13,
D14, F5, F8, F9, F13, G6,
G10, G13, H7,
DVDD
Digital power supply.
N14
MS_PWDN
3.3 V
CMOS
I
Master Powerdown. MS_PWDN driven low shuts down the PLL
and TRI-STATE all outputs, putting the device into a low power
’sleep’ mode. Default at Low.
S
www.national.com
16
