參數資料
型號： MCP2510T-E/P
元件分類： 微控制器/微處理器
英文描述： 2 CHANNEL(S), 1M bps, LOCAL AREA NETWORK CONTROLLER, PDIP18
封裝： 0.300 INCH, PLASTIC, DIP-18
文件頁數： 20/76頁
文件大?。?/td> 1076K
代理商： MCP2510T-E/P
1999 Microchip Technology Inc.
Preliminary
DS21291C-page 27
MCP2510
REGISTER 4-5:
RXBNSIDL - Receive Buffer N Standard Identifier Low (ADDRESS: 62h, 72h)
REGISTER 4-6:
RXBNEID8 - Receive Buffer N Extended Identifier Mid (ADDRESS: 63h, 73h)
REGISTER 4-7:
RXBNEID0 - Receive Buffer N Extended Identifier Low (ADDRESS: 64h, 74h)
R-x
U-0
R-x
SID2
SID1
SID0
SRR
IDE
—
EID17
EID16
R = Readable bit
W = Writable bit
C = Bit can be cleared by
MCU but not set
U = Unimplemented -
reads as ‘0’
- n = Value at POR reset
bit 7
bit 0
bit 7-5:
SID<2:0>: Standard Identifier Bits <2:0>
These bits contain the three least significant bits of the Standard Identifier for the received message
bit 4:
SRR: Standard Frame Remote Transmit Request Bit (valid only if IDE bit = ‘0’)
1 = Standard Frame Remote Transmit Request Received
0 = Standard Data Frame Recieved
bit 3:
IDE: Extended Identifier Flag
This bit indicates whether the received message was a Standard or an Extended Frame
1 = Received message was an Extended Frame
0 = Received message was a Standard Frame
bit 2:
Unimplemented: Reads as '0'
bit 1-0: EID<17:16>: Extended Identifier Bits <17:16>
These bits contain the two most significant bits of the Extended Identifier for the received message
R-x
EID15
EID14
EID13
EID12
EID11
EID10
EID9
EID8
R = Readable bit
W = Writable bit
C = Bit can be cleared by
MCU but not set
U = Unimplemented -
reads as ‘0’
- n = Value at POR reset
bit 7
bit 0
bit 7-0:
EID<15:8>: Extended Identifier Bits <15:8>
These bits hold bits 15 through 8 of the Extended Identifier for the received message
R-x
EID7
EID6
EID5
EID4
EID3
EID2
EID1
EID0
R = Readable bit
W = Writable bit
C = Bit can be cleared by
MCU but not set
U = Unimplemented -
reads as ‘0’
- n = Value at POR reset
bit 7
bit 0
bit 7-0:
EID<7:0>: Extended Identifier Bits <7:0>
These bits hold the least significant eight bits of the Extended Identifier for the received message
