| 型號： | MAX19005CCS+ |
| 廠商： | Maxim Integrated Products |
| 文件頁數： | 4/25頁 |
| 文件大?。?/td> | 0K |
| 描述： | IC DCL QUAD 300MHZ ATE 80TQFP |
| 標準包裝： | 119 |
| 系列： | ATE |
| 邏輯類型： | 比較器, 驅動器 |
| 電源電壓： | -1 V ~ 5.2 V |
| 位數： | 4 |
| 工作溫度： | 0°C ~ 70°C |
| 安裝類型： | * |
| 封裝/外殼： | * |
| 供應商設備封裝： | * |
| 包裝： | * |
Maxim Integrated Products 12
MAX19005
Quad, Ultra-Low-Power,
200Mbps ATE Drivers/Comparators
Typical Operating Characteristics
(VDD = 8V, VSS = -5V, VL = 3V, VDDSW = 24.6V, VSSSW = 1.25V, VCOMPHI = 1V, VCOMPLO = 0V, VLDV_ = 0V, LOAD EN LOW =
LOAD EN HIGH = 0, SWEN = 1, temperature coefficients TJ = +70°C are measured at TJ = +50°C to +90°C, unless otherwise noted.)
DRIVER SMALL-SIGNAL RESPONSE
MAX19005
toc01
2.0ns/div
50mV/div
0
VDLV_ = 0V
RL = 50I
VDHV_ = 500mV
VDHV_ = 200mV
VDHV_ = 100mV
DRIVER LARGE-SIGNAL RESPONSE
MAX19005
toc02
2.0ns/div
300mV/div
0
VDLV_ = 0V
RL = 50I
VDHV_ = 3V
VDHV_ = 1V
DRIVER LARGE-SIGNAL
RESPONSE INTO 500I
MAX19005
toc03
2.0ns/div
500mV/div
0
VDLV_ = 0V
RL = 500I
CL = 0.1pF
VDHV_ = +3V
VDHV_ = +1V
DRIVER 1VP-P, 150Mbps
SIGNAL RESPONSE
MAX19005
toc04
2ns/div
100mV/div
0
VDLV_ = 0V
VDHV_ = +1V
RL = 50I
DRIVER 1VP-P, 400Mbps
SIGNAL RESPONSE
MAX19005
toc05
1ns/div
100mV/div
0
VDLV_ = 0V
VDHV_ = +1V
RL = 50I
DRIVER 3VP-P, 100Mbps
SIGNAL RESPONSE
MAX19005
toc06
2.5ns/div
250mV/div
0
VDLV_ = 0V
VDHV_ = +3V
R= 50I
DRIVER 3VP-P, 250Mbps
SIGNAL RESPONSE
MAX19005
toc07
1.25ns/div
250mV/div
0
VDLV_ = 0V
VDHV_ = +3V
RL = 50I
DRIVER DC CURRENT—
LIMIT RESPONSE
MAX19005
toc08
VDUT_ (V)
I DUT_
(mA)
6
4
0
2
-60
-40
-20
0
40
20
60
80
-80
-2
8
VDHV_ = 3V
DUT_ = DHV_
DRIVER 3V TRAILING-EDGE
TIMING ERROR vs. PULSE WIDTH
MAX19005
toc09
PULSE WIDTH (ns)
TIMING
ERROR
(ps)
12
11
9 10
5
6
7
8
4
-70
-60
-50
-40
-30
-20
-10
0
10
20
-80
313
NORMALIZED AT PW = 12.5ns,
PERIOD = 25ns, VDHV_ = +3V, VDLV_ = 0V
NEGATIVE PULSE
POSITIVE PULSE
