參數資料
型號： MAX19005CCS+
廠商： Maxim Integrated Products
文件頁數： 21/25頁
文件大?。?/td> 0K
描述： IC DCL QUAD 300MHZ ATE 80TQFP
標準包裝： 119
系列： ATE
邏輯類型： 比較器, 驅動器
電源電壓： -1 V ~ 5.2 V
位數： 4
工作溫度： 0°C ~ 70°C
安裝類型： *
封裝/外殼： *
供應商設備封裝： *
包裝： *
Maxim Integrated Products 5
MAX19005
Quad, Ultra-Low-Power,
200Mbps ATE Drivers/Comparators
ELECTRICAL CHARACTERISTICS (continued)
(VDD = +8V, VSS = -5V, VL = +3V, VDDSW = +24.6V, VSSSW = -1.25V, VCOMPHI = +1V, VCOMPLO = 0V, VLDV__= 0V, LOAD EN
LOW_ = LOAD EN HIGH_ = 0, SWEN = 1, TJ = +70°C with an accuracy of ±15NC. Specification compliance with supply and
temperature variations is verified by guard-banding mean shifts of characterization data, unless otherwise noted. All temperature
coefficients measured at TJ = +50°C to +90°C, unless otherwise noted.) (Note 1)
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
Prop-Delay Skew, Comparators
Within Package
Same edges (LH and HL),
VDUT_ = 1VP-P
Q
100
ps
Prop-Delay Dispersions vs.
Common-Mode Voltage (Note 12)
VCHV_ or VCLV_ = 0 to +4.9V,
VDUT_= 0.2VP-P
Q
20
ps
VCHV_ or VCLV_ = -0.9 to +4.9V,
VDUT_= 0.2VP-P
Q
30
Prop-Delay Dispersions vs. Overdrive
VDLV_ = 0V termination mode,
VDUT_ = 1VP-P, tR = tF = 500ps input,
90% (rising edge) and 10% (falling edge)
relative to timing at 50% point
Q
600
ps
Prop-Delay Dispersions vs.
Pulse Width
2ns to 23ns pulse width, relative to
12.5ns pulse width
Q
60
ps
Prop-Delay Dispersions vs.
Slew Rate
+0.5V/ns to +2V/ns
Q
50
ps
LOGIC INPUTS AND OUTPUTS (COMPHI, COMPLO, CMPH, CMPL, VBBO)
Input Voltage Range,
VCOMPHI and VCOMPLO
0
3.6
V
Differential Input Voltage,
VCOMPHI - VCOMPLO
VCOMPHI R VCOMPLO, CMPH_ and
CMPL_ with no load
0
3.6
V
Differential Input Voltage,
VCOMPHI - VCOMPLO
VCOMPHI R VCOMPLO, CMPH_ and
CMPL_ with 50I to VTTCMP, VCOMPHI R
VTTCMP R VCOMPLO
0
1.0
V
Reference Output,
VBBO
Relative to (VCOMPHI + VCOMPLO)/2 at
VCOMPHI = +1V and VCOMPLO = 0V
Q
50
mV
Output High-Voltage Offset
IOUT = 0mA, relative to VCOMPHI at
VCOMPHI = +1V
Q
65
mV
Output Low-Voltage Offset
IOUT = 0mA, relative to VCOMPLO at
VCOMPLO_ = 0V
Q
65
mV
Output Resistance,
CMPH_ and CMPL_
ICMPH_ = ICMPL_ = Q10mA, VCOMPHI =
+1V, VCOMPLO = 0V, CMPH_, CMPL_ at
high-level output
40
50
60
I
Maximum Current Limit,
CMPH_ and CMPL_
VCOMPHI = +1.8V, VCOMPLO = 0V,
CMPH_, CMPL_ at high-level output,
VFORCE = 0V, +3.6V
-15
+15
mA
Maximum Current Limit,
VBBO
VCOMPHI = +1V, VCOMPLO = 0V, at
VBBO = +0.5V output
-1
+1
mA
