SINGLE-CHIP 8-BIT CMOS MICROCOMPUTER with CLOSED CAPTION DECODER
and ON-SCREEN DISPLAY CONTROLLER
MITSUBISHI MICROCOMPUTERS
M37151M6/M8/MA/MC/MF-XXXFP, M37151EFFP
39
Rev 1.0
8.6.10 Example of Master Transmission
An example of master transmission in the standard clock mode, at
the SCL frequency of 100 kHz with the ACK return mode enabled, is
shown below.
Set a slave address in the high-order 7 bits of the I
2
C address
register (address 00F7
16
) and “0” in the RBW bit.
Set the ACK return mode and SCL = 100 kHz by setting “85
16
” in
the I
2
C clock control register (address 00FA
16
).
Set “10
16
” in the I
2
C status register (address 00F8
16
) and hold the
SCL at HIGH.
Set a communication enable status by setting “48
16
” in the I
2
C
control register (address 00F9
16
).
Set the address data of the destination of transmission in the high-
order 7 bits of the I
2
C data shift register (address 00F6
16
) and set
“0” in the least significant bit.
Set “F0
16
” in the I
2
C status register (address 00F8
16
) to generate
a START condition. At this time, an SCL for 1 byte and an ACK
clock automatically occurs.
Set transmit data in the I
2
C data shift register (address 00F6
16
). At
this time, an SCL and an ACK clock automatically occurs.
When transmitting control data of more than 1 byte, repeat step
.
Set “D0
16
” in the I
2
C status register (address 00F8
16
). After this, if
ACK is not returned or transmission ends, a STOP condition will
be generated.
8.6.11 Example of Slave Reception
An example of slave reception in the high-speed clock mode, at the
SCL frequency of 400 kHz, with the ACK Non-return mode enabled
while using the addressing format, is shown below.
Set a slave address in the high-order 7 bits of the I
2
C address
register (address 00F7
16
) and “0” in the RBW bit.
Set the ACK non-return mode and SCL = 400 kHz by setting “25
16
”
in the I
2
C clock control register (address 00FA
16
).
Set “10
16
” in the I
2
C status register (address 00F8
16
) and hold the
SCL at HIGH.
Set a communication enable status by setting “48
16
” in the I
2
C
control register (address 00F9
16
).
When a START condition is received, an address comparison is
executed.
When all transmitted address are“0” (general call):
AD0 of the I
2
C status register (address 00F8
16
) is set to “1” and
an interrupt request signal occurs.
When the transmitted addresses match the address set in
:
ASS of the I
2
C status register (address 00F8
16
) is set to “1” and
an interrupt request signal occurs.
In the cases other than the above:
AD0 and AAS of the I
2
C status register (address 00F8
16
) are set
to
“0” and no interrupt request signal occurs.
Set dummy data in the I
2
C data shift register (address 00F6
16
).
When receiving control data of more than 1 byte, repeat step
.
When a STOP condition is detected, the communication ends.
