M30245 Group
2. Power Control
Figure 2.16.4. Power control-related registers
Bit Symbol
Bit Name
Function
R W
O O
Symbol
CM0
Address
000616
When reset
4816
System clock control register 0 (Note 1)
b7
b5
b6
b4
b3
b2
b1
b0
CM02
CM03
CM04
CM05
CM06
CM07
WAIT peripheral function
clock stop bit
Xcin-Xcout drive capacity
select bit (Note 2)
Port Xc select bit
Main clock (Xin-Xout)
stop bit (Note 3, 4, 5)
Main clock division select
bit 0 (Note 7)
System clock select bit
(Note 6)
0 : Do not stop in wait mode
1 : Stop in wait mode (Note 8)
0 : LOW
1 : HIGH
0 : I/O port
1 : Xcin-Xcout generation
0 : On
1 : Off
0 : CM16 and CM17 valid
1 : Divide-by-8 mode
0 : Xin, Xout
1 : Xcin, Xcout
O O
Note 1: Set bit 0 of the protect register (address 000A16) to “1” before writing to this register.
Note 2: Changes to “1” when changing to stop mode and at a reset.
Note 3: When entering power saving mode, main clock stops using this bit. When returning from
stop mode and operating in XIN, set this bit to “0”. When main clock oscillation is operating
by itself, set system clock select bit (CM07) to “1” before setting this bit to “1”.
Note 4: When inputting external clock, only clock oscillation buffer is stopped and clock input is
acceptable.
Note 5: If this bit is set to “1”, XOUT becomes “H”. The built-in feedback resistor remains connected,
so XIN becomes pulled up to Xout (“H”) using the feedback resistor.
Note 6: Set port Xc select bit (CM04) to “1”, and stabilize the sub clock oscillating before setting to
this bit from “0” to “1”. Do not write to both bits at the same time. Also, set the main clock
stop bit (CM05) to “0”, and stabilize the main clock oscillating before setting this bit from
“1” to “0”.
Note 7: This bit changes to “1”, when changing from high-speed/medium mode to stop mode and at
reset. When shifting from low-speed/low power dissipation mode to stop mode, the value
before stop mode is retained.
Note 8: fC32 is not included. Do not set to “1” when using low-speed or low power dissipation mode.
Note 9: When the XCIN/XCOUT is used, set ports P86 and P87 as the input ports without pull-up.
Bit Symbol
Bit Name
Function
R W
O O
Symbol
CM1
Address
000716
When reset
2016
System clock control register 1 (Note 1)
b7
b5
b6
b4
b3
b2
b1
b0
CM10
Reserved bit
CM15
CM16
CM17
All clock stop control bit
(Note 4)
0 : Clock on
1 : All clocks off (stop mode)
Always set to “0”
0 : LOW
1 : HIGH
b7 b6
0 0 : No division mode
0 1 : Divide-by-2 mode
1 0 : Divide-by-4 mode
1 1 : Divide-by-16 mode
O O
Xin-Xout drive capacity
select bit (Note 2)
Main clock division select
bit 1 (Note 3)
0
Note 1: Set bit 0 of the protect register (address 000A16) to “1” before writing to this register.
Note 2: This bit changes to “1”, when changing from high-speed/medium mode to stop mode and at
reset. When shifting from low-speed/low power dissipation mode to stop mode, the value
before stop mode is retained.
Note 3: Can be selected when bit 6 of the system clock control register 0 (address 000616) is “0”.
If “1”, division mode is fixed at 8.
Note 4: If this bit is set to “1”, XOUT turns “H”, and the built-in feedback resistor is cut off. XCIN and
XCOUT turn high-impedance state.
Reserved bit
Always set to “0”
00
