Serial I/O
Under
development
Tentative Specifications REV.C1
Specifications in this manual are tentative and subject to change.
Mitsubishi microcomputers
M30100/M30101/M30102 Group
SINGLE-CHIP 16-BIT CMOS MICROCOMPUTER
84
LSB first
When transfer format select bit = “0”
D0
D0
D1
D2
D3
D4
D5
D6
D7
D1
D2
D3
D4
D5
D6
D7
TXDi
RXDi
CLKi
When transfer format select bit = “1”
D6
D5
D4
D3
D2
D1
D0
D7
D6
D5
D4
D3
D2
D1
D0
TXDi
RXDi
CLKi
MSB first
Note: This applies when the CLK polarity select bit = “0”.
Clock synchronous serial I/O mode
When CLK polarity select bit = “1”
Note 2: The CLKi pin level when not
transferring data is “L”.
D1
D2
D3
D4
D5
D6
D7
D1
D2
D3
D4
D5
D6
D7
D0
TXDi
RXDi
CLKi
When CLK polarity select bit = “0”
Note 1: The CLKi pin level when not
transferring data is “H”.
D1
D2
D3
D4
D5
D6
D7
D0
D1
D2
D3
D4
D5
D6
D7
D0
TXDi
RXDi
CLKi
(a) Polarity select function
As shown in Figure 1.15.8, the CLK polarity select bit (bit 6 at addresses 00A416 and 00AC16) allows
selection of the polarity of the transfer clock.
(b) LSB first/MSB first select function
As shown in Figure 1.15.9, when the transfer format select bit (bit 7 at addresses 00A416 and 00AC16)
= “0”, the transfer format is “LSB first”; when the bit = “1”, the transfer format is “MSB first”.
Figure 1.15.8. Polarity of transfer clock
Figure 1.15.9. Transfer format
