15/33
M29KW016E
STATUS REGISTER
Bus Read operations from any address always
read the Status Register during Program and
Erase operations. The bits in the Status Register
are summarized in Table 8., Status Register Bits.
Data Polling Bit (DQ7). The Data Polling Bit can
be used to identify whether the Program/Erase
Controller has successfully completed its opera-
tion. The Data Polling Bit is output on DQ7 when
the Status Register is read.
During a Word Program operation the Data Polling
Bit outputs the complement of the bit being pro-
grammed to DQ7. After successful completion of
the Word Program operation the memory returns
to Read mode and Bus Read operations from the
address just programmed output DQ7, not its com-
plement. The Data Polling Bit is not available dur-
ing a Multiple Word Program operation.
During Erase operations the Data Polling Bit out-
puts ’0’, the complement of the erased state of
DQ7. After successful completion of the Erase op-
eration the memory returns to Read Mode.
Figure 7., Data Polling Flowchart, gives an exam-
ple of how to use the Data Polling Bit. A Valid Ad-
dress is the address being programmed or an
address within the block being erased.
Toggle Bit (DQ6). The Toggle Bit can be used to
identify whether the Program/Erase Controller has
successfully completed its operation. The Toggle
Bit is output on DQ6 when the Status Register is
read.
During Program and Erase operations the Toggle
Bit changes from ’0’ to ’1’ to ’0’, etc., with succes-
sive Bus Read operations at any address. After
successful completion of the operation the memo-
ry returns to Read mode.
Figure 8., Data Toggle Flowchart, Data Toggle
Flowchart, gives an example of how to use the
Data Toggle Bit.
Error Bit (DQ5). The Error Bit can be used to
identify errors detected by the Program/Erase
Controller. The Error Bit is set to ’1’ when a Pro-
gram, Block Erase or Chip Erase operation fails to
write the correct data to the memory. If the Error
Bit is set a Read/Reset command must be issued
before other commands are issued. The Error bit
is output on DQ5 when the Status Register is read.
Note that the Program command cannot change a
bit set to ’0’ back to ’1’ and attempting to do so will
set DQ5 to ‘1’. A Bus Read operation to that ad-
dress will show the bit is still ‘0’. One of the Erase
commands must be used to set all the bits in a
block or in the whole memory from ’0’ to ’1’.
VPP Status Bit (DQ4). The VPP Status Bit can be
used to identify if any Program or Erase operation
has failed due to a VPP error. If VPP falls below VHH
during any Program or Erase operation, the oper-
ation aborts and DQ4 is set to ‘1’. If VPP remains at
VHH throughout the Program or Erase operation,
the operation completes and DQ4 is set to ‘0’.
Erase Timer Bit (DQ3). The Erase Timer Bit can
be used to identify the start of Program/Erase
Controller operation during a Block Erase com-
mand. Once the Program/Erase Controller starts
erasing the Erase Timer Bit is set to ’1’. The Erase
Timer Bit is output on DQ3 when the Status Reg-
ister is read.
Alternative Toggle Bit (DQ2). The
Alternative
Toggle Bit can be used to monitor the Program/
Erase controller during Block and Chip Erase op-
erations. The Alternative Toggle Bit is output on
DQ2 when the Status Register is read.
During Erase operations the Toggle Bit changes
from ’0’ to ’1’ to ’0’, etc., with successive Bus Read
operations to any address. Once the operation
completes the memory returns to Read mode.
If an Erase operation fails and the Error Bit is set,
the Alternative Toggle Bit will continue to toggle
with successive Bus Read operations to any ad-
dress. The Alternative Toggle Bit does not change
if the addressed block has erased correctly.
Multiple Word Program Bit (DQ0). The Multiple
Word Program Bit can be used to indicate whether
the Program/Erase Controller is active or inactive
during Multiple Word Program. When the Pro-
gram/Erase Controller has written one Word and is
ready to accept the next Word, the bit is set to ‘0’.
Status Register Bit DQ1 is reserved.
