K6F1616U6M Family
Preliminary
CMOS SRAM
Revision 0.1
November 2000
8
Address
Data Valid
UB, LB
WE
Data in
Data out
High-Z
High-Z
TIMING WAVEFORM OF WRITE CYCLE(3)
(UB, LB Controlled)
NOTES
(WRITE CYCLE)
1. A wri
t
e occurs during the overlap(t
WP
) of low CS
1
and low WE. A write begins when CS
1
goes low and WE goes low with asserting
UB or LB for single byte operation or simultaneously asserting UB and LB for double byte operation. A write ends at the earliest tran-
sition when CS
1
goes high and WE goes high. The
t
WP
is measured from the beginning of write to the end of write.
2.
t
CW
is measured from the CS
1
going low to end of write.
3.
t
AS
is measured from the address valid to the beginning of write.
4.
t
WR
is measured from the end or write to the address change.
t
WR
applied in case a write ends as CS
1
or WE going high.
t
WC
t
CW(2)
t
BW
t
WP(1)
t
DH
t
DW
t
WR(4)
t
AW
DATA RETENTION WAVE FORM
CS
1
,
LB/UB controlled
V
CC
2.7V
2.2V
V
DR
CS
1
,LB/UB
GND
Data Retention Mode
CS
1
≥
V
CC
- 0.2V, LB=UB
≥
V
CC
- 0.2V
t
SDR
t
RDR
t
AS(3)
CS
1
CS
2
CS
2
controlled
V
CC
2.7V
CS
2
0.4V
GND
V
DR
Data Retention Mode
t
SDR
t
RDR
CS
2
≤
0.2V
