F
FDS6630A Rev. C1
FDS6630A
N-Channel Logic Level PowerTrench
TM
MOSFET
General Description
This N-Channel Logic Level MOSFET is produced using
Fairchild Semiconductor's advanced PowerTrench process
that has been especially tailored to minimize on-state
resistance and yet maintain superior switching
performance.
These devices are well suited for low voltage and battery
powered applications where low in-line power loss and
fast switching are required.
Applications
DC/DC converter
Load switch
Motor drives
April 1999
Features
6.5 A, 30 V. R
DS(on)
= 0.038
@ V
GS
= 10 V
R
DS(on)
= 0.053
@ V
GS
= 4.5 V
Low gate charge (5nC typical).
Fast switching speed.
High performance trench technology for extremely
low R
DS(ON)
.
High power and current handling capability.
1999 Fairchild Semiconductor Corporation
Absolute Maximum Ratings
T
A
= 25°C unless otherwise noted
Symbol
Parameter
Ratings
Units
V
DSS
V
GSS
I
D
Drain-Source Voltage
Gate-Source Voltage
Drain Current
30
±
20
6.5
40
2.5
1.2
1
V
V
A
- Continuous
- Pulsed
(Note 1a)
P
D
Power Dissipation for Single Operation
(Note 1a)
W
(Note 1b)
(Note 1c)
T
J
, T
stg
Operating and Storage Junction Temperature Range
-55 to +150
°
C
Thermal Characteristics
R
θ
JA
R
θ
JC
Thermal Resistance, Junction-to-Ambient
Thermal Resistance, Junction-to-Case
(Note 1a)
50
25
°
C/W
°
C/W
(Note 1)
Package Outlines and Ordering Information
Device Marking
FDS6630A
Device
FDS6630A
Reel Size
13’’
Tape Width
12mm
Quantity
2500 units
S
D
S
S
SO-8
D
D
D
G
pin
1
6
7
8
5
3
2
1
4
