28F160S3, 28F320S3
E
40
ADVANCE INFORMATION
6.0
ELECTRICAL SPECIFICATIONS
6.1
Absolute Maximum Ratings
Temperature under Bias................
–40°C to +85°C
Storage Temperature................... –65°C to +125°C
Voltage On Any Pin
(except V
CC
and V
PP
)
....................................–0.5V to + V
CC
+0.5V
(1)
V
CC
Supply Voltage ............–0.2V to + V
CC
+0.5V
(1)
V
PP
Update Voltage during
Block Erase, Flash Write, and
Lock-Bit Configuration ........... –0.2V to +7.0V
(2)
Output Short Circuit Current.....................100 mA
(3)
NOTICE: This datasheet contains information on products
in the design phase of development. Do not finalize a
design with this information. Revised information will be
published when the product is available. Verify with your
local Intel Sales office that you have the latest datasheet
before finalizing a design
*WARNING: Stressing the device beyond the
“Absolute
Maximum Ratings” may cause permanent damage. These
are stress ratings only. Operation beyond the “Operating
Conditions” is not recommended and extended exposure
beyond the “Operating Conditions” may affect device
reliability
.
NOTES:
1. All specified voltages are with respect to GND. Minimum
DC voltage is
–0.5V on input/output pins and –0.2V on
V
CC
and V
PP
pins. During transitions, this level may
undershoot to –2.0V for periods <20 ns. Maximum DC
voltage on input/output pins and V
CC
is V
CC
+0.5V
which, during transitions, may overshoot to V
CC
+2.0V
for periods <20 ns.
2. Maximum DC voltage on V
PP
may overshoot to +7.0V
for periods <20 ns.
3. Output shorted for no more than one second. No more
than one output shorted at a time.
4. Operating temperature is for extended product defined
by this specification.
6.2
Operating Conditions
Table 17. Temperature and V
CC
Operating Conditions
(1)
Symbol
Parameter
Notes
Min
Max
Unit
Test Condition
T
A
Operating Temperature
-40
+85
°C
Ambient Temperature
V
CC1
V
CC
Supply Voltage (2.7V to 3.6V)
2.7
3.6
V
V
CC2
V
CC
Supply Voltage (3.3V ± 0.3V)
3.0
3.6
V
NOTES:
1.
Device operations in the V
CC
voltage ranges not covered in the table produce spurious results and should not be
attempted.
