APTGF25H120T3
A
APT website – http://www.advancedpower.com
1 - 6
Absolute maximum ratings
Symbol
V
CES
Collector - Emitter Breakdown Voltage
Parameter
Max ratings
1200
40
25
100
±20
208
50A@1150V
Unit
V
T
C
= 25°C
T
C
= 80°C
T
C
= 25°C
T
C
= 25°C
T
j
= 125°C
I
C
Continuous Collector Current
I
CM
V
GE
P
D
RBSOA
These Devices are sensitive to Electrostatic Discharge. Proper Handing Procedures Should Be Followed.
Pulsed Collector Current
Gate – Emitter Voltage
Maximum Power Dissipation
Reverse Bias Safe Operating Area
A
V
W
Q3
11
10
Q1
CR1
7
22
13
14
CR3
3
30
29
32
18
19
23
8
15
31
R1
16
4
CR4
CR2
Q2
Q4
26
27
16
15
18
20
23 22
13
11 12
14
8
7
29
30
28 27 26
3
32
31
10
19
2
25
4
All multiple inputs and outputs must be shorted together
Example: 13/14 ; 29/30 ; 22/23 …
V
CES
= 1200V
I
C
= 25A @ Tc = 80°C
Application
Features
Welding converters
Switched Mode Power Supplies
Uninterruptible Power Supplies
Motor control
Non Punch Through (NPT) Fast IGBT
-
Low voltage drop
-
Low tail current
-
Switching frequency up to 50 kHz
-
Soft recovery parallel diodes
-
Low diode VF
-
Low leakage current
-
Avalanche energy rated
-
RBSOA and SCSOA rated
-
Symmetrical design
Kelvin emitter for easy drive
Very low stray inductance
High level of integration
Internal thermistor for temperature monitoring
Benefits
Outstanding performance at high frequency
operation
Direct mounting to heatsink (isolated package)
Low junction to case thermal resistance
Solderable terminals both for power and signal
for easy PCB mounting
Low profile
Easy paralleling due to positive TC of VCEsat
Each leg can be easily paralleled to achieve a
phase leg of twice the current capability
Full - Bridge
NPT IGBT Power Module
