Absolute Maximum Ratings
(Notes 1, 2)
Supply Voltage (V
A)
3.8V
Driver Supply Voltage (V
DR)VA +0.3V
Voltage on Any Input or Output Pin
0.3V to V
A
Reference Voltage (V
RT,VRB)VA to AGND
CLK, PD Voltage Range
0.05V to
(V
A + 0.05V)
Input Current at Any Pin (Note 3)
±25 mA
Package Input Current (Note 3)
±50 mA
Power Dissipation at T
A = 25C (Note 4)
969mW
Thermal Resistance
θ
JA
Still Air
129C/W
θ
JA
500LF/Min Air Flow
72C/W
θ
JC
25C/W
Soldering Temperature,
10 seconds
260C
Storage Temperature
65C to +150C
ESD Susceptibility (Note 5)
Human Body Model
Machine Model
2500V
200V
Recommended Operating Ratings (Notes 1, 2)
Operating Temperature Range
55C
≤ T
A
≤ +125C
Supply Voltage (V
A)
+2.7V to +3.6V
Driver Supply Voltage (V
DR)
+2.4V to V
A
Ground Difference |GND - DR GND|
0V to 300 mV
Upper Reference Voltage (V
RT)
0.5V to (V
A 0.3V)
Lower Reference Voltage (V
RB)
0Vto(V
RT 0.5V)
V
IN Voltage Range
V
RB to VRT
ADC08200QML
www.national.com
4
