2SC5999
No.8029-1/4
Applications
Relay drivers, lamp drivers, motor drivers, inverters.
Features
Adoption of MBIT process.
Large current capacitance.
Low collector-to-emitter saturation voltage.
High-speed switching.
Surface mount type.
Specifications
Absolute Maximum Ratings
at Ta=25
°
C
Parameter
Symbol
VCBO
VCES
VCEO
VEBO
IC
ICP
IB
Conditions
Ratings
Unit
V
V
V
V
A
A
A
W
W
°
C
°
C
Collector-to-Base Voltage
Collector-to-Emitter Voltage
Collector-to-Emitter Voltage
Emitter-to-Base Voltage
Collector Current
Collector Current (Pulse)
Base Current
120
120
50
6
25
40
2
Collector Dissipation
PC
1.65
40
150
Tc=25
°
C
Junction Temperature
Storage Temperature
Tj
Tstg
--55 to +150
Electrical Characteristics
at Ta=25
°
C
Ratings
typ
Parameter
Symbol
Conditions
min
max
Unit
Collector Cutoff Current
Emitter Cutoff Current
ICBO
IEBO
hFE1
hFE2
VCB=100V, IE=0
VEB=4V, IC=0
VCE=2V, IC=1A
VCE=2V, IC=15A
10
10
560
μ
A
μ
A
DC Current Gain
200
150
Continued on next page.
Ordering number : ENN8029
D2404FA TS IM TB-00000425
2SC5999
NPN Epitaxial Planar Silicon Transistors
High-Current Switching Applications
SANYO Electric Co.,Ltd. Semiconductor Company
TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110-8534 JAPAN
Any and all SANYO products described or contained herein do not have specifications that can handle
applications that require extremely high levels of reliability, such as life-support systems, aircraft's
control systems, or other applications whose failure can be reasonably expected to result in serious
physical and/or material damage. Consult with your SANYO representative nearest you before using
any SANYO products described or contained herein in such applications.
SANYO assumes no responsibility for equipment failures that result from using products at values that
exceed, even momentarily, rated values (such as maximum ratings, operating condition ranges, or other
parameters) listed in products specifications of any and all SANYO products described or contained
herein.
