SLLSE66A
– OCTOBER 2010 – REVISED SEPTEMBER 2011
PIN FUNCTIONS
PIN
I/O
DESCRIPTION
Y0P, Y0M, Y1P,
Differential LVDS data outputs.
Y1M, Y2P, Y2M
Outputs are high-impedance when SHTDN is pulled low (de-asserted)
Differential LVDS Data outputs.
Y3P, Y3M
LVDS Out
Output is high-impedance when SHTDN is pulled low (de-asserted).
Note: if the application only requires 18-bit color, this output can be left open.
Differential LVDS pixel clock output.
CLKP, CLKM
Output is high-impedance when SHTDN is pulled low (de-asserted).
Data inputs; supports 1.8V to 3.3V input voltage selectable by VDD supply. To connect a graphic
source successfully to a display, the bit assignment of D[27:0] is critical (and not necessarily
intuitive).
D0
– D27
For input bit assignment see Figure 11 to Figure 14 for details.
Note: if application only requires 18-bit color, connect unused inputs D5, D10, D11, D16, D17, D23,
and D27 to GND.
CMOS IN with
pulldn
CLKIN
Input pixel clock; rising or falling clock polarity is selectable by Control input CLKSEL.
Device shut down; pull low (de-assert) to shut down the device (low power, resets all registers) and
SHTDN
high (assert) for normal operation.
Selects between rising edge input clock trigger (CLKSEL = VIH and falling edge input clock trigger
CLKSEL
(CLKSEL = VIL).
VCC
3.3V digital supply voltage
IOVCC
I/O supply reference voltage (1.8V up to 3.3V matching the GPU data output signal swing)
PLLVCC
Power Supply(1)
3.3V PLL analog supply
LVDSVCC
3.3V LVDS output analog supply
GND
Supply ground for VCC, IOVCC, LVDSVCC, and PLLVCC.
(1)
For a multilayer pcb, it is recommended to keep one common GND layer underneath the device and connect all ground terminals
directly to this plane.
Copyright
2010–2011, Texas Instruments Incorporated
5
Product Folder Link(s): SN75LVDS83C
