1.
General description
The SA58643 is a wideband RF switch fabricated in BiCMOS technology and
incorporating on-chip CMOS/TTL compatible drivers. Its primary function is to switch
signals in the frequency range DC to 1 GHz from one 50
channel to another. The switch
is activated by a CMOS/TTL compatible signal applied to the enable channel 1 pin
(ENCH1).
The extremely low current consumption makes the SA58643 ideal for portable
applications. The excellent isolation and low loss makes this a suitable replacement for
PIN diodes.
The SA58643 is available in an 8-pin TSSOP package.
2.
Features
I
Wideband (DC to 1 GHz)
I
Low through loss (1 dB typical at 200 MHz)
I
Unused input is terminated internally in 50
I
Excellent overload capability (1 dB gain compression point +18 dBm at 300 MHz)
I
Low DC power (170
μ
A from 5 V supply)
I
Fast switching (20 ns typical)
I
Good isolation (off channel isolation 60 dB at 100 MHz)
I
Low distortion (IP3 intercept +33 dBm)
I
Good 50
match (return loss 18 dB at 400 MHz)
I
Full ESD protection
I
Bidirectional operation
3.
Applications
I
Digital transceiver front-end switch
I
Antenna switch
I
Filter selection
I
Video switch
I
FSK transmitter
SA58643
Single-Pole Double-Throw (SPDT) switch
Rev. 01 — 20 November 2006
Product data sheet
