1998 Microchip Technology Inc.
Preliminary
DS35008B-page 81
PIC16C62B/72A
13.0
Absolute Maximum Ratings
()
Ambient temperature under bias............................................................................................................
.-55°C to +125°C
Storage temperature.............................................................................................................................. -65°C to +150°C
Voltage on any pin with respect to V
SS
(except V
DD
, MCLR, and RA4)..........................................-0.3V to (V
DD
+ 0.3V)
Voltage on V
DD
with respect to V
SS
......................................................................................................... -0.3V to +7.5V
Voltage on MCLR with respect to V
SS
(Note 2).......................................................................................... 0V to +13.25V
Voltage on RA4 with respect to Vss............................................................................................................... 0V to +8.5V
Total power dissipation (Note 1)................................................................................................................................1.0W
Maximum current out of V
SS
pin ...........................................................................................................................300 mA
Maximum current into V
DD
pin..............................................................................................................................250 mA
Input clamp current, I
IK
(V
I
< 0 or V
I
> V
DD
)
......................................................................................................................±
20 mA
Output clamp current, I
OK
(V
O
< 0 or V
O
> V
DD
)
..............................................................................................................±
20 mA
Maximum output current sunk by any I/O pin..........................................................................................................25 mA
Maximum output current sourced by any I/O pin ....................................................................................................25 mA
Maximum current sunk by
PORTA and PORTB (combined).................................................................................200 mA
Maximum current sourced by PORTA and PORTB (combined)............................................................................200 mA
Maximum current sunk by PORTC........................................................................................................................200 mA
Maximum current sourced by PORTC ..................................................................................................................200 mA
Note 1:
Power dissipation is calculated as follows: Pdis = V
DD
x {I
DD
-
∑
I
OH
} +
∑
{(V
DD
-V
OH
) x I
OH
} +
∑
(V
O
l x I
OL
)
2:
Voltage spikes below V
SS
at the MCLR/V
PP
pin, inducing currents greater than 80 mA, may cause latch-up.
Thus, a series resistor of 50-100
should be used when applying a “l(fā)ow” level to the MCLR/V
PP
pin, rather
than pulling this pin directly to V
SS
.
ELECTRICAL CHARACTERISTICS
NOTICE: Stresses above those listed under “Absolute Maximum Ratings” may cause permanent damage to the
device. This is a stress rating only and functional operation of the device at those or any other conditions above those
indicated in the operation listings of this specification is not implied. Exposure to maximum rating conditions for
extended periods may affect device reliability.
