2
RF Device Data
Freescale Semiconductor
MRF8P20160HR3 MRF8P20160HSR3
Table 2. Thermal Characteristics
Characteristic
Symbol
Value (1,2)
Unit
Thermal Resistance, Junction to Case
Case Temperature 81°C, 37 W CW, 28 Vdc, IDQA = 550 mA, VGSB = 1.3 Vdc, 1900 MHz
RθJC
0.75
°C/W
Table 3. ESD Protection Characteristics
Test Methodology
Class
Human Body Model (per JESD22--A114)
2 (Minimum)
Machine Model (per EIA/JESD22--A115)
A (Minimum)
Charge Device Model (per JESD22--C101)
IV (Minimum)
Table 4. Electrical Characteristics (TA =25°C unless otherwise noted)
Characteristic
Symbol
Min
Typ
Max
Unit
Off Characteristics (3)
Zero Gate Voltage Drain Leakage Current
(VDS =65 Vdc, VGS =0 Vdc)
IDSS
—
10
μAdc
Zero Gate Voltage Drain Leakage Current
(VDS =28 Vdc, VGS =0 Vdc)
IDSS
—
1
μAdc
Gate--Source Leakage Current
(VGS =5 Vdc, VDS =0 Vdc)
IGSS
—
1
μAdc
On Characteristics (3)
Gate Threshold Voltage
(VDS =10 Vdc, ID =116 μAdc)
VGS(th)
1.2
1.8
2.7
Vdc
Gate Quiescent Voltage
(VDD =28 Vdc, IDA = 550 mAdc, Measured in Functional Test)
VGS(Q)
1.9
2.7
3.4
Vdc
Drain--Source On--Voltage
(VGS =10 Vdc, ID =1.5 Adc)
VDS(on)
0.1
0.27
0.5
Vdc
Functional Tests (4,5) (In Freescale Doherty Test Fixture, 50 ohm system) VDD =28 Vdc, IDQA = 550 mA, VGSB =1.6 Vdc, Pout =37 W Avg.,
f = 1920 MHz, Single--Carrier W--CDMA
, IQ Magnitude Clipping, Input Signal PAR = 9.9 dB @ 0.01% Probability on CCDF. ACPR
measured in 3.84 MHz Channel Bandwidth @ ±5MHz Offset.
Power Gain
Gps
15.5
16.5
18.5
dB
Drain Efficiency
ηD
43.5
45.8
—
%
Output Peak--to--Average Ratio @ 0.01% Probability on CCDF
PAR
6.4
6.9
—
dB
Adjacent Channel Power Ratio
ACPR
—
--30.6
--28.5
dBc
Typical Broadband Performance (5) (In Freescale Doherty Test Fixture, 50 ohm system) VDD =28 Vdc, IDQA = 550 mA, VGSB =1.6 Vdc,
Pout = 37 W Avg., f = 1920 MHz, Single--Carrier W--CDMA, IQ Magnitude Clipping, Input Signal PAR = 9.9 dB @ 0.01% Probability on
CCDF. ACPR measured in 3.84 MHz Channel Bandwidth @ ±5MHz Offset.
Frequency
Gps
(dB)
ηD
(%)
Output PAR
(dB)
ACPR
(dBc)
1880 MHz
16.5
44.8
7.0
--29.8
1900 MHz
16.6
45.3
6.9
--30.1
1920 MHz
16.5
45.8
6.9
--30.6
1. MTTF calculator available at http://www.freescale.com/rf. Select Software & Tools/Development Tools/Calculators to access MTTF
calculators by product.
2. Refer to AN1955, Thermal Measurement Methodology of RF Power Amplifiers. Go to http://www.freescale.com/rf.
Select Documentation/Application Notes -- AN1955.
3. Each side of device measured separately.
4. Part internally matched both on input and output.
5. Measurement made with device in a Symmetrical Doherty configuration.
(continued)
