參數資料
型號： ML9044A-XXACVWA
廠商： LAPIS SEMICONDUCTOR CO LTD
元件分類： 顯示控制器
英文描述： 17 X 120 DOTS DOT MAT LCD DRVR AND DSPL CTLR, UUC189
封裝： GOLD BUMP, DIE-189
文件頁數： 64/65頁
文件大小： 726K
代理商： ML9044A-XXACVWA
PEDL9044A-04
OKI Semiconductor
ML9044A-xxA/xxB
7/64
ABSOLUTE MAXIMUM RATINGS
(GND = 0 V)
Parameter
Symbol
Condition
Rating
Unit
Applicable pins
Supply Voltage
VDD
Ta = 25°C
–0.3 to +6.5
V
VDD–GND
LCD Driving Voltage
V1, V2, V3,
V4, V5
Ta = 25°C
VDD–7.5 to VDD+0.3
V
V1, V4, V5, V5IN, V2, V3A, V3B
Input Voltage
VI
Ta = 25°C
–0.3 to VDD+0.3
V
R/
W, E, SHT, CSR, S/P,
SSR, Sl, RS0, RS1, BE, CS,
T1 to T3, DB0 to DB7, VIN
Storage Temperature
TSTG
—
–55 to +150
°C
—
RECOMMENDED OPERATING CONDITIONS
(GND = 0 V)
Parameter
Symbol
Condition
Range
Unit
Applicable pins
Supply Voltage
VDD
—
2.7 to 5.5
V
VDD–GND
LCD Driving Voltage
VDD–V5
(See Note)
—
3.3 to 7.0
V
VDD–V5
(V5IN)
Voltage Multipler
Operating Voltage
VMUL
BE = “1”
2.7 to 3.5
V
VDD–VIN
Operating Temperature
Top
—
–40 to +85
°C
—
Note: This voltage should be applied across VDD and V5. The following voltages are output to the V1, V2,
V3A (V3B) and V4 pins:
1/4 bias
V1 = {VDD – (VDD – V5)/4} ±0.15 V
V2 = V3B = {VDD – (VDD – V5)/2} ±0.15 V
V4 = {VDD – 3
× (V
DD – V5)/4 } ±0.15 V
1/5 bias
V1 = {VDD – (VDD – V5)/5} ±0.15 V
V2 = {VDD – 2
× (V
DD – V5)/5} ±0.15 V
V3A = V3B = {VDD – 3
× (V
DD – V5)/5} ±0.15 V
V4 = {VDD – 4
× (V
DD – V5)/5} ±0.15 V
The voltages at the V1, V2, V3A (V3B), V4 and V5 pins should satisfy
VDD > V1 > V2 > V3A (V3B) > V4 > V5.
(Higher
←
→ Lower)
* If the chip is attached on a substrate using COG technology, the chip tends to be susceptible
to electrical characteristics of the chip due to trace resistance on the glass substrate. It is
recommended to use the chip by confirming that it operates on the glass substrate properly.
Trace resistance, especially, VDD and VSS trace resistance, between the chip on the LCD
panel and the flexible cable should be designed as low as possible. Trace resistance that
cannot be very well decreased, larger size of the LCD panel, or greater trace capacitance
between the microcontroller and the ML9044A device can cause device malfunction. In order
to avoid the device malfunction, power noise should be reduced by serial interfacing of the
microcontroller and the ML9044A device.
* Do not apply short-circuiting across output pins and across an output pin and an input/output
pin or the power supply pin in the output mode.
