PEDL9044A-04
OKI Semiconductor
ML9044A-xxA/xxB
5/64
Symbol
Description
CSR
The input pin to select the transfer direction of the common signal output data.
At 1/n duty, data is transferred from COM1 to COMn when “L” is applied to this pin and
transferred from COMn to COM1 when “H” is applied to this pin.
SSR
The input pin to select the transfer direction of the segment signal output data.
“L”: Data transfer from SEG1 to SEG120
“H”: Data transfer from SEG120 to SEG1
V1 , V2, V3A, V3B, V4
The pins to output bias voltages to the LCD.
For 1/4 bias : The V2 and V3B pins are shorted.
For 1/5 bias : The V3A and V3B pins are shorted.
BE
The input pin to enable or disable the voltage multiplier circuit.
"L" disables the voltage multiplier circuit. "H" enables the voltage multiplier circuit.
The voltage multiplier circuit doubles the input voltage between VDD and VIN and the
multiplied voltage referenced to VDD is output to the V5IN pin. The voltage multiplier
circuit can be used only when generating a level lower than GND.
VIN
The pin to input voltage to the voltage multiplier.
V5, V5IN
The pins to supply the LCD drive voltage.
The LCD drive voltage is supplied to the V5 pin when the voltage multiplier is not used
(BE = “0”) and the internal contrast adjusting circuit is also not used. At this time, the
V5IN pin should be open.
The LCD drive voltage is supplied to the V5IN pin when the voltage multiplier is not used
(BE = “0”) but the internal contrast adjusting circuit is used. At this time, the V5 pin
should be open.
When the voltage multiplier is used (BE = “1”), the V5 pin should be open (the
multiplied voltage is output to the V5IN pin). In this case, the internal contrast adjusting
circuit must be used. Capacitors for the voltage multiplier should be connected
between the VDD pin and the V5IN pin.
VC
The pin to connect the positive pin of the capacitor for the voltage multiplier. Leave the
pin open when the voltage multiplier circuit is not used.
VCC
The pin to connect the negative pin of the capacitor used for the voltage multiplier.
Leave the pin open when the voltage multiplier circuit is not used.
