MK2731-01
LOW COST VCXO
VCXO
IDT / ICS LOW COST VCXO
4
MK2731-01
REV E 021804
Absolute Maximum Ratings
Stresses above the ratings listed below can cause permanent damage to the MK2731-01. These ratings, which are
standard values for ICS commercially rated parts, are stress ratings only. Functional operation of the device at
these or any other conditions above those indicated in the operational sections of the specifications is not implied.
Exposure to absolute maximum rating conditions for extended periods can affect product reliability. Electrical
parameters are guaranteed only over the recommended operating temperature range.
Recommended Operation Conditions
DC Electrical Characteristics
VDD=3.3 V ±5% , Ambient temperature 0 to +70
°C, unless stated otherwise
Item
Rating
Supply Voltage, VDD
7 V
All Inputs and Outputs
-0.5 V to VDD+0.5 V
Ambient Operating Temperature
0 to +70
°C
Storage Temperature
-65 to +150
°C
Soldering Temperature
260
°C
Parameter
Min.
Typ.
Max.
Units
Ambient Operating Temperature
0
+70
°C
Power Supply Voltage (measured in respect to GND)
+4.75
+5.25
V
Reference crystal parameters
Refer to page 3
Parameter
Symbol
Conditions
Min.
Typ.
Max.
Units
Operating Voltage
VDD
4.75
5.25
V
Output High Voltage
VOH
IOH = -25 mA
2.4
V
Output Low Voltage
VOL
IOL = 25 mA
0.4
V
Output High Voltage (CMOS
Level)
VOH
IOH = -8 mA
VDD-0.4
V
Input High Voltage (X1 only)
VIH
3.5
2.5
V
Input High Voltage
VIH
2.0
V
Input Low Voltage (X1 only)
VIL
2.5
1.5
V
Input Low Voltage
VIL
0.8
V
Operating Supply Current
IDD
No load, S2:0 =
000
20
mA
Short Circuit Current
IOS
Each output
±100
mA
VIN, VCXO Control Voltage
VIA
03
V
Frequency Synthesis Error
All clocks
0
ppm
Input Capacitance
CIN
S0, S1, S2, OE
7
pF
