參數資料
型號： KSZ8895MQ
廠商： Micrel Inc
文件頁數： 97/119頁
文件大小： 0K
描述： IC ETHERNET SW 5PORT 128-PQFP
標準包裝： 66
控制器類型： 以太網開關控制器
接口： MII
電源電壓： 1.8V，2.5V，3.3V
工作溫度： 0°C ~ 70°C
安裝類型： 表面貼裝
封裝/外殼： 128-BFQFP
供應商設備封裝： 128-PQFP（14x20）
包裝： 托盤
配用： 576-3871-ND - BOARD EVALUATION FOR KSZ8895MQ
其它名稱： 576-3753
Micrel, Inc.
KSZ8895MQ/RQ/FMQ
Advanced Control Registers (Continued)
Address
Name
Description
Mode
Default
4–0
Unknown IP multicast packet
forward port map
00000 = filter unknown IP multiicast packet
00001 = forward unknown IP multicast packet to
port 1.
00010 = forward unknown IP multicast packet to
port 2.
00011 = forward unknown IP multicast packet to
port 1, port 2
……
11111 = broadcast unknown IP multicast packet to
all ports
R/W
00000
Register 135 (0x87): Global Control 19
7
Reserved
N/A Do not change.
RO
0
6
Reserved
N/A Do not change.
RO
0
5–4
Ingress Rate Limit Period
The unit period for calculating Ingress Rate Limit
00 = 16 ms
01 = 64 ms
1x = 256 ms
R/W
01
3
Queue-based Egress Rate
Limit Enabled
Enable Queue-based Egress Rate Limit
0 = port-base Egress Rate Limit (default)
1 = queue-based Egress Rate Limit
R/W
0
2
Insertion Source Port PVID
Tag Selection Enable
1 = enable source port PVID tag insertion or non-
insertion option on the egress port for each source
port PVID based on the ports registers control 8.
0 = disable, all packets from any ingress port will be
inserted PVID based on port register control 0 bit 2.
R/W
0
1–0
Reserved
N/A Do not change
RO
00
Register 144 (0x90): TOS Priority Control Register 0
The Ipv4/Ipv6 TOS priority control registers implement a fully decoded 64 bit differentiated services code point (DSCP) register used to
determine priority from the 6 bit TOS field in the IP header. The most significant 6 bits of the TOS field are fully decoded into 64
possibilities, and the singular code that results is mapped to the value in the corresponding bit in the DSCP register.
7–6
DSCP[7:6]
Ipv4 and Ipv6 mapping
The value in this field is used as the frame’s priority
when bits[7:2] of the frame’s IP TOS/DiffServ/Traffic
Class value is 0x03
R/W
00
5–4
DSCP[5:4]
Ipv4 and Ipv6 mapping
The value in this field is used as the frame’s priority
when bits[7:2] of the frame’s IP TOS/DiffServ/Traffic
Class value is 0x02
R/W
00
3–2
DSCP[3:2]
Ipv4 and Ipv6 mapping
The value in this field is used as the frame’s priority
when bits[7:2] of the frame’s IP TOS/DiffServ/Traffic
Class value is 0x01
R/W
00
March 12, 2014
79
Revision 1.7
相關PDF資料
PDF描述
KSZ8993FL IC CONV MED 10/100 SGL 128PQFP
KSZ8993MLI IC SWITCH 10/100 3PORT 128-PQFP
KSZ8993ML IC SWITCH 10/100 W/TXRX 128PQFP
KSZ8995FQ IC SWITCH 10/100 5PORT 128-PQFP
KSZ8995MA IC SWITCH 10/100 5PORT 128PQFP
