參數資料
| 型號： | ICS951403YGLF-T |
| 元件分類： | 時鐘產生/分配 |
| 英文描述： | 166.67 MHz, PROC SPECIFIC CLOCK GENERATOR, PDSO48 |
| 封裝： | 0.240 INCH, 0.020 INCH PITCH, LEAD FREE, MO-153, TSSOP-48 |
| 文件頁數： | 16/18頁 |
| 文件大?。?/td> | 639K |
| 代理商： | ICS951403YGLF-T |
7
ICS951403
0486B—02/23/04
Absolute Maximum Ratings
Supply Voltage . . . . . . . . . . . . . . . . . . . . . . . . . 5.5 V
Logic Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . GND –0.5 V to VDD +0.5 V
Ambient Operating Temperature . . . . . . . . . . 0°C to +70°C
Storage Temperature . . . . . . . . . . . . . . . . . . . . –65°C to +150°C
Stresses above those listed under
Absolute Maximum Ratings may cause permanent damage to the device. These
ratings are stress specifications only and functional operation of the device at these or any other conditions above those
listed in the operational sections of the specifications is not implied. Exposure to absolute maximum rating conditions
for extended periods may affect product reliability.
Electrical Characteristics - Input/Supply/Common Output Parameters
TA = 0 - 70°C; Supply Volt age VDD = 3.3 V +/-5% (unless otherwise stated)
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
Input High Voltage
VIH
2VDD + 0.3
V
Input Low Voltage
VIL
VSS - 0.3
0.8
V
Input High Current
IIH
VIN = VDD
5
A
Input Low Current
IIL1
VIN=0 V; Inputs with no pull-up resistors
-5
uA
Input Low Current
IIL2
VIN=0 V; Inputs with pull-up resistors
-200
uA
Supply Current
IDD3.3OP
CL = Full load
213
240
mA
Power Down
PD
0.07
0.6
mA
Input frequency
Fi
VDD = 3.3 V;
12
14.318
16
MHz
CIN
Logic Inputs
5
pF
Input Capacitance1
CIN
Logic Inputs
5
pF
CINX
X1 & X2 pins
27
45
pF
Clk Stabilization
1
TSTAB
From VDD= 3.3 V to 1% target Freq.
3
ms
Skew
1
tCPU-SDRAM
CPU Xover to SDRAM 1.5V
68
250
ps
Skew
1
tCPU-PCI
CPU Xover to PCI 1.5V
186
250
ps
Skew
1
tCPU-AGP
CPU Xover to AGP 1.5V
138
500
ps
1 Guaranteed by design, not 100% tested in production.
