Advance Information
PowerNPTM NPe405H Embedded Processor Data Sheet
45
System Interface
SysClk
Main System Clock input.
I
3.3V Analog
Wire w/ESD
SysReset
Main System Reset.
I/O
5V tolerant
3.3V LVTTL
1, 2
SysErr
Set to 1 when a Machine Check is generated.
O
5V tolerant
3.3V LVTTL
Halt
Halt from external debugger.
I
5V tolerant
3.3V LVTTL
1, 4
CGPIO0:31
Communicatons General Purpose I/O.
I/O
5V tolerant
3.3V LVTTL
SGPIO0:31
System General Purpose I/O.
I/O
5V tolerant
3.3V LVTTL
TestEn
Test Enable. Used only for manufacturing tests. Pull down
for normal operation.
I
3.3V LVTTL
Rcvr w/ PD
3
TmrClk
This input must toggle at a rate of less than one half the
CPU core frequency (less than 100MHz in most cases). In
most cases this input toggles much slower (in the 1MHz to
10MHz range).
I
5V tolerant
3.3V LVTTL
1, 4
Trace Interface
[TS1E]
[TS2E]
Even Trace execution status.To access this function,
software must toggle a DCR bit.
O
5V tolerant
3.3V LVTTL
[TS1O]
[TS2O]
Odd Trace execution status. To access this function,
software must toggle a DCR bit.
O
5V tolerant
3.3V LVTTL
[TS3:6]
Trace Status. To access this function, software must toggle
a DCR bit.
O
5V tolerant
3.3V LVTTL
[TrcClk]
Trace interface clock. A toggling signal that is always half
of the CPU core frequency. To access this function,
software must toggle a DCR bit.
O
5V tolerant
3.3V LVTTL
1
Power Pins
GND
Ground
Note: J09-J14, K09-K14, L09-L14, M09-M14, N09-N14,
and P09-P14 are also thermal balls.
I
Hardwire
VDD
Logic voltage—2.5V
I
Hardwire
OVDD
Output driver voltage—3.3V
I
Hardwire
AVDD
Filtered PLL voltage—2.5V
I
3.3V DC
Wire w/ESD
Other Pins
Reserved
Do not connect signals, voltage, or ground to these pins.
n/a
Signal Functional Description (Part 9 of 9)
Notes:
1. Receiver input has hysteresis
2. Must pull up (recommended value is 3k
to 3.3V, 10k to 5V)
3. Must pull down (recommended value is 1k
)
4. If not used, must pull up (recommended value is 3k
to 3.3V)
5. If not used, must pull down (recommended value is 1k
)
Signal Name
Description
I/O
Type
Notes
