參數資料
型號： FT232RL-REEL
廠商： FTDI, Future Technology Devices International Ltd
文件頁數： 9/43頁
文件大?。?/td> 0K
描述： IC USB FS SERIAL UART 28-SSOP
產品培訓模塊： USB Introduction
USB-UART Interface Solutions
標準包裝： 1
系列： USBmadeEZ-UART
特點： USB 至 UART
通道數： 1，UART
FIFO's： 256 字節
規程： RS232，RS422，RS485
電源電壓： 3.3 V ~ 5.25 V
帶自動流量控制功能： 是
帶調制解調器控制功能： 是
帶CMOS： 是
安裝類型： 表面貼裝
封裝/外殼： 28-SSOP（0.209"，5.30mm 寬）
供應商設備封裝： 28-SSOP
包裝： 標準包裝
產品目錄頁面： 634 (CN2011-ZH PDF)
配用： 768-1023-ND - MOD USB RS232 DEV/EVAL FT232RL
768-1022-ND - MOD USB UART MINI B DEV FT232R
768-1021-ND - MOD USB UART MINI DEV FT232R
768-1019-ND - MOD USB UART DEV FT232R
其它名稱： 768-1007-6
Copyright 2010 Future Technology Devices International Limited
17
Document No.: FT_000053
FT232R USB UART IC Datasheet Version 2.10
Clearance No.: FTDI# 38
5 Devices Characteristics and Ratings
5.1 Absolute Maximum Ratings
The absolute maximum ratings for the FT232R devices are as follows. These are in accordance with the
Absolute Maximum Rating System (IEC 60134). Exceeding these may cause permanent damage to the
device.
Parameter
Value
Unit
Storage Temperature
-65°C to 150°C
Degrees C
Floor Life (Out of Bag) At Factory Ambient
(30°C / 60% Relative Humidity)
168 Hours
(IPC/JEDEC J-STD-033A MSL Level 3
Compliant)*
Hours
Ambient Temperature (Power Applied)
-40°C to 85°C
Degrees C
MTTF FT232RL
11162037
hours
MTTF FT232RQ
4464815
hours
VCC Supply Voltage
-0.5 to +6.00
V
DC Input Voltage – USBDP and USBDM
-0.5 to +3.8
V
DC Input Voltage – High Impedance
Bidirectionals
-0.5 to + (VCC +0.5)
V
DC Input Voltage – All Other Inputs
-0.5 to + (VCC +0.5)
V
DC Output Current – Outputs
24
mA
DC Output Current – Low Impedance
Bidirectionals
24
mA
Power Dissipation (VCC = 5.25V)
500
mW
Table 5.1 Absolute Maximum Ratings
* If devices are stored out of the packaging beyond this time limit the devices should be baked before
use. The devices should be ramped up to a temperature of +125°C and baked for up to 17 hours.
