| 型號： | D2-24044-MR |
| 廠商： | Intersil |
| 文件頁數： | 19/20頁 |
| 文件大小： | 0K |
| 描述： | IC DGTL AMP AUDIO PWR D 38HTSSOP |
| 標準包裝： | 50 |
| 系列： | D2Audio™ |
| 類型： | D 類 |
| 輸出類型： | 2-通道（立體聲）或 4 通道（四路） |
| 在某負載時最大輸出功率 x 通道數量： | 30W x 2 @ 8 歐姆 |
| 電源電壓： | 9 V ~ 26 V |
| 安裝類型： | 表面貼裝 |
| 供應商設備封裝： | 38-HTSSOP |
| 封裝/外殼： | 38-TFSOP （0.173"，4.40mm 寬）裸露焊盤 |
| 包裝： | 管件 |
8
FN7678.0
September 3, 2010
Typical Performance Characteristics
37
HGNDA
GND
HV
Output stage A high voltage supply ground. A separate ground pin connection is provided
for each of the output stages. All of the HGND[A:D] pins connect to system “HV” power
ground (also see Note 8).
38
HVDDA
P
HV
Output stage A high voltage supply power. A separate power pin connection is provided
for each of the output stages. All of the HVDD[A:D] pins and the VDDHV pin connect to
the system “HV” power source.
NOTES:
7. Unless otherwise specified all pin names are active high. Those that are active low have an “n” prefix, such as nERRORA.
8. Thermal pad is internally connected to all 4 HGND ground pins (HGNDA, HGNDB, HGNDC, HGNDD). Any connection to the
thermal pad must be made to the common ground for these 4 ground pins.
Pin Description (Continued)
PIN
PIN NAME
(Note 7)
TYPE
VOLTAGE
LEVEL
(V)
DESCRIPTION
Full-Bridge Typical Performance Curves
FIGURE 1. THD vs POWER, FULL-BRIDGE
FIGURE 2. THD vs FREQUENCY, FULL-BRIDGE
FIGURE 3. FREQUENCY RESPONSE, FULL-BRIDGE
FIGURE 4. NOISE FLOOR, FULL-BRIDGE
0.01
10.00
0.02
0.05
0.10
0.20
0.50
1.00
2.00
5.00
THD
(%)
0.06
50
0.1
0.2
0.5
1
2
5
10
20
POWER (W)
HVDD = 24.0V,
8Ω LOAD, 1kHz
0.001
1.000
0.002
0.005
0.010
0.020
0.050
0.100
0.200
0.500
20
20k
50
100 200
500
1k
2k
5k
10k
FREQUENCY (Hz)
P = 25W
THD
(%)
P = 14W
P = 7W
P = 1W
HVDD = 24.0V, 8Ω LOAD,
AT 1W, 7W, 14W, 25W POWER OUT
-6
6
-5
-4
-3
-2
-1
-0
1
2
3
4
5
dBr
A
30
10k
50
100 200
500
1k
2k
5k
FREQUENCY (Hz)
HVDD = 24.0V,
8Ω LOAD, 3.5W
-120
-50
-115
-110
-105
-100
-95
-90
-85
-80
-75
-70
-65
-60
-55
dBr
A
-60
+0
-55 -50 -45 -40 -35 -30 -25 -20 -15 -10 -5
dBFS
< -115dB, UN-WEIGHTED
HVDD = 24.0V, 8Ω LOAD,
AT 1kHz, REFERENCE TO 30W
D2-24044
