AMD
2-205
PAL22V10-7 (Com’l)
CAPACITANCE (Note 1)
Parameter
Symbol
Parameter Description
Test Conditions
Typ
Unit
C
IN
Input Capacitance
V
IN
= 2.0 V
6
C
OUT
Output Capacitance
V
OUT
= 2.0 V
5
Note:
1. These parameters are not 100% tested, but are evaluated at initial characterization and at any time the design is modified
where capacitance may be affected.
V
CC
= 5.0 V
T
A
= 25
°
C
f = 1 MHz
pF
SWITCHING CHARACTERISTICS over COMMERCIAL operating ranges (Note 2)
Parameter
Symbol
Min
Parameter Description
(Note 3)
Max
Unit
t
PD
Input or Feedback to Combinatorial Output
1
7.5
ns
t
S
Setup Time from Input, Feedback or SP to Clock
5
ns
t
H
Hold Time
0
ns
t
CO
Clock to Output
1
6
ns
t
SKEWR
Skew Between Registered Outputs (Note 5)
1
ns
t
AR
Asynchronous Reset to Registered Output
12
ns
t
ARW
Asynchronous Reset Width
8
ns
t
ARR
Asynchronous Reset Recovery Time
8
ns
t
SPR
Synchronous Preset Recovery Time
5
ns
t
WL
LOW
4
ns
t
WH
HIGH
4
ns
External Feedback
1/(t
S
+ t
CO
)
91
MHz
f
MAX
Internal Feedback (f
CNT
)
1/(t
S
+ t
CF
) (Note 6)
100
MHz
No Feedback
1/(t
WH
+ t
WL
)
125
MHz
t
EA
Input to Output Enable Using Product Term Control
8
ns
t
ER
Input to Output Disable Using Product Term Control
7.5
ns
Clock Width
Maximum
Frequency
(Note 4)
Notes:
2. See Switching Test Circuit for test conditions.
3. Output delay minimums are measured under best-case conditions.
4. These parameters are not 100% tested, but are calculated at initial characterization and at any time the design is modified
where frequency may be affected.
5. Skew is measured with all outputs switching in the same direction.
6. t
CF
is a calculated value and is not guaranteed. t
CF
can be found using the following equation:
t
CF
= 1/f
MAX
(internal feedback) – t
S
.
