2SC5819
2001-12-17
1
TOSHIBA Transistor Silicon NPN Epitaxial Type
2SC5819
High-Speed Switching Applications
DC-DC Converter Applications
High DC current gain: h
FE
= 400 to 1000 (I
C
= 0.15 A)
Low collector-emitter saturation voltage: V
CE (sat)
= 0.12 V (max)
High-speed switching: t
f
= 45 ns (typ.)
Maximum Ratings
(Ta 25°C)
Characteristics
Symbol
Rating
Unit
Collector-base voltage
V
CBO
40
V
Collector-emitter voltage
V
CEX
30
V
Collector-emitter voltage
V
CEO
20
V
Emitter-base voltage
V
EBO
7
V
DC
I
C
1.5
Collector current
Pulse
I
CP
2.5
A
Base current
I
B
150
mA
t 10 s
2.0
Collector power
dissipation
DC
P
C
(Note 1)
1.0
W
Junction temperature
T
j
150
°C
Storage temperature range
T
stg
55 to 150
°C
Note 1: Mounted on FR4 board (glass epoxy, 1.6 mm thick, Cu area:
645 mm
2
)
Electrical Characteristics
(Ta 25°C)
Characteristics
Symbol
Test Condition
Min
Typ.
Max
Unit
Collector cut-off current
I
CBO
V
CB
40 V, I
E
0
100
nA
Emitter cut-off current
I
EBO
V
EB
7 V, I
C
0
100
nA
Collector-emitter breakdown voltage
V
(BR) CEO
I
C
10 mA, I
B
0
20
V
h
FE
(1)
V
CE
2 V, I
C
0.15 A
400
1000
DC current gain
h
FE
(2)
V
CE
2 V, I
C
0.5 A
200
Collector-emitter saturation voltage
V
CE (sat)
I
C
0.5 A, I
B
10 mA
0.12
V
Base-emitter saturation voltage
V
BE (sat)
I
C
0.5 A, I
B
10 mA
1.10
V
Collector output capacitance
C
ob
V
CB
10 V, I
E
0, f 1 MHz
18
pF
Rise time
t
r
43
Storage time
t
stg
295
Switching time
Fall time
t
f
See Figure 1 circuit diagram.
V
CC
12 V, R
L
24
I
B1
I
B2
17 mA
45
ns
Industrial Applications
Unit: mm
JEDEC
―
JEITA
SC-62
TOSHIBA
2-5K1A
Weight: 0.05 g (typ.)
