XRT5894
4
Rev. 1.10
PIN DESCRIPTION
Pin #
Symbol
Type
Description
1
LOS1
O
Receiver 1 Loss of Signal.
Asserted during LOS condition.
2
RXPOS1
O
Receiver 1 Positive Data Out.
Positive RZ data output for channel 1.
3
RXNEG1
O
Receiver 1 Negative Data Out.
Negative RZ data output for channel 1.
4
V
CC
RTIP1
Positive Supply (+3.3V or +5.0V + 5%).
Digital circuitry.
5
I
Receiver 1 Positive Bipolar Input.
6
RRING1
I
Receiver 1 Negative Bipolar Input.
7
V
CC
GND
Positive Supply (+3.3V or +5.0V + 5%).
Analog circuitry.
8
Analog Ground.
9
V
CC
GND
Positive Supply. (+3.3V or +5.0V + 5%).
Analog circuitry.
10
Analog Ground.
11
TRING2
O
Transmitter 2 Negative Bipolar Output.
12
V
CC
TTIP2
Positive Supply (+3.3V or +5.0V + 5%
)
.
Transmitter channel 2.
13
O
Transmitter 2 Positive Bipolar Output.
14
GND
Analog Ground.
Transmitter channel 2.
15
RTIP2
I
Receiver 2 Positive Bipolar Input.
16
RRING2
I
Receiver 2 Negative Bipolar Input.
Transmitter 2 Clock Input.
Use for clocked mode with NRZ data.
1
Transmitter 2 Negative Data Input.
Negative NRZ or RZ data input.
1
Transmitter 2 Positive Data Input.
Positive NRZ or RZ data input.
1
17
TXCLK2
I
18
TXNEG2
I
19
TXPOS2
I
20
LOS2
O
Receiver 2 Loss of Signal.
Asserted during LOS condition.
21
RXPOS2
O
Receiver 2 Positive Data Out.
Positive RZ data output for channel 2.
22
RXNEG2
O
Receiver 2 Negative Data Out.
Negative RZ data output for channel 2.
23
V
CC
NC
Positive Supply (+3.3V or +5.0V + 5%).
Digital circuitry.
24
No Connect.
Loss of Signal Delay Select.
“Hi” selects G.775, “Lo” selects user programmable.
1
25
LOSSEL
I
26
GND
Digital Ground.
27
RXNEG3
O
Receiver 3 Negative Data Out.
Negative RZ data output for channel 3.
28
RXPOS3
O
Receiver 3 Positive Data Out.
Positive RZ data output for channel 3.
29
LOS3
O
Receiver 3 Loss of Signal.
Asserted during LOS condition.
Transmitter 3 Positive Data Input.
Positive NRZ or RZ data input.
1
Transmitter 3 Negative Data Input.
Negative NRZ or RZ data input.
1
Transmitter 3 Clock Input.
Use for clocked mode with NRZ data.
1
30
TXPOS3
I
31
TXNEG3
I
32
TXCLK3
I
33
RRING3
I
Receiver 3 Negative Bipolar Input.
34
RTIP3
I
Receiver 3 Positive Bipolar Input.
Note
:
1
Has internal pull-up 50K
resistor.
