XRT5894
2
Rev. 1.10
RZ
BLOCK DIAGRAM
Figure 1. XRT5894 Block Diagram
RTIP4 (43)
RRING4 (42)
LOSSEL (25)
TXCLK4 (51)
TTIP4 (53)
TRING4 (55)
LOS4 (48)
TXPOS4 (49)
TXNEG4 (50)
RXNEG4 (46)
RXPOS4 (47)
LOSCNT (45)
Signal
Peak
Detector
LOS
Detect
Loss
Delay
Counter
Mux
O
Pulse
Shaping
To
Duty
Cycle
Adjust
Mux
0
0
2:1
1:2
R1
RING
RING
TIP
RX Input
TIP
TX OUTPUT
Receive
Comparators
Drivers
R2
R3
9.1
R4
9.1
Transceiver 2
Transceiver 3
Tranceiver 4
Transceiver 1
1
1
1
TrLine
V
CC
Receiver Notes
D
The same type 1:2CT ratio transformer may be
used at the receiver input and transmitter output.
D
R1 and R2 are both 150
for 75
operation, or
240
for 120
operation.
D
Return loss exceeds ITU G.703 specification with
these resistors and a 1:2CT ratio input transformer.
LOS (Loss of Signal) Notes
D
LOSSEL (pin 25) is connected to logic “1” for ITU
G.775 compliant LOS delay, or to logic 0 for user
programmable additional delay.
D
LOSCNT (pin 45) is unconnected when LOSSEL is
logic 1, or connected to an external clock when
LOSSEL is logic 0.
Transmitter Notes
D
Return loss exceeds ETSI 300 166 specification
with a 1:2 ratio transformer.
D
R3 and R4 are always 9.1
for both 75
and 120
applications.
