3
White Electronic Designs Corporation (602) 437-1520 www.wedc.com
White Electronic Designs
W72M64VK-XBX
April 2005
Rev. 0
ABSOLUTE MAXIMUM RATINGS
Parameter
Unit
Operating Temperature
-55 to +125
°C
Supply Voltage Range (VCC)
-0.5 to +4.0
V
Signal Voltage Range
-0.5 to Vcc +0.5
V
Storage Temperature Range
-55 to +150
°C
Endurance (write/erase cycles)
1,000,000 min.
cycles
NOTES:
1.
Stresses above the absolute maximum rating may cause permanent damage to the
device. Extended operation at the maximum levels may degrade performance and
affect reliability.
RECOMMENDED OPERATING CONDITIONS
Parameter
Symbol
Min
Max
Unit
Supply Voltage
VCC
3.0
3.6
V
Operating Temp. (Mil.)
TA
-55
+125
°C
Operating Temp. (Ind.)
TA
-40
+85
°C
CAPACITANCE
TA = +25°C, F = 1.0MHz
Parameter
Symbol
Max
Unit
WE1-4# capacitance
CWE
8
pF
CS1-4# capacitance
CCS
8pF
Data I/O capacitance
CI/O
10
pF
Address input capacitance
CAD
30
pF
RESET# capacitance
CRS
26
pF
RY/BY# capacitance
CRB
26
pF
OE# capacitance
COE
32
pF
This parameter is guaranteed by design but not tested.
DATA RETENTION
Parameter
Test Conditions
Min
Unit
Pattern Data
Retention Time
150°C
10
Years
125°C
20
Years
DC CHARACTERISTICS – CMOS COMPATIBLE
VCC = 3.3V ± 0.3V, -55°C ≤ TA ≤ +125°C
Parameter
Symbol
Conditions
Min
Max
Unit
Input Leakage Current
ILI
VCC = 3.6V, VIN = GND to VCC
-10
10
A
Output Leakage Current
ILO
VCC = 3.6V, VOUT = GND to VCC
-10
10
A
VCC Active Current for Read (1)
ICC1
CS# = VIL#, OE = VIH, f = 5MHz
65
mA
VCC Active Current for Program or Erase (2,3)
ICC2
CS# = VIL#, OE = VIH, WE# = VIL
120
mA
VCC Standby Current (2)
ICC3
CS# = RESET# = VCC ± 0.3V
400
A
Automatic Sleep Mode (2,4,5)
ICC5
VIH = VCC ± 0.3V;
VIL = VSS ± 0.3V
400
A
VCC Active Read-While-Program Current (1,2)
ICC6
CS# = VIL#, OE = VIH
180
mA
VCC Active Program-While-Erase Current (1,2)
ICC7
CS# = VIL#, OE = VIH
180
mA
VCC Active Program-While-Erase-Suspended Current (2,5)
ICC8
CS# = VIL#, OE = VIH
140
mA
ACC Accelerated Program Current
IACC
CS# = VIL#, OE = VIH
ACC Pin
40
mA
VCC Pin
120
Input Low Voltage
VIL
-0.5
0.8
V
Input High Voltage
VIH
VCC = min
2.1
VCC + 0.3
V
Voltage for WP#/ACC Sector
Protect/Unprotect and Program Acceleration
VHH
VCC = 3.0V + 0.3V
8.5
9.5
V
Voltage for Autoselect and Temporary Sector Unprotect
VID
VCC = 3.0V + 0.3V
8.5
12.5
V
Output Low Voltage
VOL
IOL = 4.0 mA, VCC = 3.0V
0.45
V
Output High Voltage
VOH1
IOH = -2.0 mA, VCC = 3.0V
2.55
V
Low VCC Lock-Out Voltage (5)
VLKO
2.3
2.5
V
NOTES:
1.
The ICC current listed includes both the DC operating current and the frequency dependent component (at 5 MHz).
The frequency component typically is less than 8 mA/MHz, with OE# at VIH.
2.
Maximum ICC specications are tested with VCC = VCC MAX
3.
ICC active while Embedded Algorithm (program or erase) is in progress.
4.
Automatic sleep mode enables the low power mode when addresses remain stable for tACC + 30ns.
5.
Not tested.
