μ
PD78363A, 78365A, 78366A, 78368A
84
12. RECOMMENDED SOLDERING CONDITIONS
These products should be soldered and mounted under the conditions recommended below.
For details of recommended soldering conditions, refer to the information document
Semiconductor Device
Mounting Technology Manual (C10535E)
.
For soldering methods and conditions other than those recommended, please contact your NEC sales
representative.
Table 12-1. Surface Mount Type Soldering Conditions
μ
PD78363AGF-
×××
-3B9: 80-Pin Plastic QFP (14
×
20 mm)
μ
PD78365AGF-3B9
: 80-Pin Plastic QFP (14
×
20 mm)
μ
PD78366AGF-
×××
-3B9: 80-Pin Plastic QFP (14
×
20 mm)
μ
PD78368AGF-
×××
-3B9: 80-Pin Plastic QFP (14
×
20 mm)
Soldering method
Infrared reflow
VPS
Wave soldering
Partial heating
Caution Use of more than one soldering method should be avoided (except in the case of partial
heating).
Recommended
condition symbol
IR35-00-3
VP15-00-3
WS60-00-1
–
Soldering conditions
Package peak temperature: 235 C, Duration: 30 sec. max. (210 C or
above) Number of times: 3 max.
Package peak temperature: 215 C, Duration: 40 sec. max. (200 C or
above) Number of times: 3 max.
Solder bath temperature: 260 C or less, Time: 10 sec. max.,
Number of times: 1, Pre-heating temperature: 120 C max. (Package
surface temperature)
Pin temperature: 300 C or less
Duration: 3 sec. max. (per side of device)
