REAL-TIME PULSE UNIT (RPU)
The real-time pulse unit (RPU) can measure pulse intervals and frequencies, and output programmable
pulses (six channels of PWM control signals).
The RPU consists of five 16-bit timers (timers 0 through 4), of which one is provided with a 10-bit dead time
timer, which is ideal for inverter control. In addition, a function to turn off the output by the software or an external
interrupt is also provided.
Each timer has the following features:
Timer 0 : Controls the PWM period of the TO00 through TO05 pins. In addition, operates as a
general-purpose interval timer. Timer 0 has the following five operation modes:
General-purpose interval timer mode
PWM mode 0 (symmetrical triangular wave)
PWM mode 0 (asymmetrical triangular wave)
PWM mode 0 (saw-tooth wave)
PWM mode 1
Timer 1 : Operates as a general-purpose interval timer.
Timers 2, 3 : Has a programmable input sampling circuit that rejects the noise of an input signal,
and a capture function.
Timer 4 : Operates as a general-purpose timer or an up-down counter. When operating as a general-
purpose timer, controls the PWM cycle of the TO40 output pin. Timer 4 has the following
two operation modes:
General-purpose timer mode
Up/down counter mode (UDC mode)
