μ
PD78363A, 78365A, 78366A, 78368A
23
2.3.3
Special Function Registers (SFR)
Special function registers (SFRs) are registers assigned special functions such as mode registers and control
registers for internal peripheral hardware, and are mapped to a 256-byte address space at FF00H through
FFFFH.
Table 2-1 lists the SFRs. The meanings of the symbols in this table are as follows:
Symbol ................................... Indicates the mnemonic symbol for an SFR.
This mnemonic can be coded in the operand field of an instruction.
R/W ........................................ Indicates whether the SFR can be read or written.
R/W : Read/write
R
: Read only
W
: Write only
Bit units for manipulation ...... Indicates bit units in which the SFR can be manipulated. The SFRs that
can be manipulated in 16-bit units can be coded as an sfrp operand.
Specify an even address for these SFRs.
The SFRs that can be manipulated in 1-bit units can be coded as the
operand of bit manipulation instructions.
On reset ................................. Indicates the status of the register at RESET input.
Cautions 1. Do not access the addresses in the range FF00H through FFFFH to which no special
function register is allocated. If these addresses are accessed, malfunctioning may
occur.
2. Do not write data to the read-only registers. Otherwise, the internal circuit may not
operate normally.
3. When using read data as byte data, process undefined bit(s) first.
4. TOUT and TXS are write-only registers. Do no read these registers.
5. Bits 0, 1, and 4 of SBIC are write-only bits. When these bits are read, they are always
"0".
