DESCRIPTION/ORDERING INFORMATION
SCDS246A – JUNE 2007 – REVISED AUGUST 2008 ....................................................................................................................................................... www.ti.com
The TS3L500AE is a 16-bit to 8-bit multiplexer/demultiplexer LAN switch with a single select (SEL) input. SEL
controls the data path of the multiplexer/demultiplexer. The device provides additional I/Os for switching status
indicating LED signals and includes high ESD protection.
The device provides a low and flat ON-state resistance (ron) and an excellent ON-state resistance match. Low
input/output capacitance, high bandwidth, low skew, and low crosstalk among channels make this device suitable
for various LAN applications, such as 10/100/1000 Base-T.
This device can be used to replace mechanical relays in LAN applications. It also can be used to route signals
from a 10/100 Base-T ethernet transceiver to the RJ-45 LAN connectors in laptops or in docking stations.
ORDERING INFORMATION
TA
PACKAGE(1).(2)
ORDERABLE PART NUMBER
TOP-SIDE MARKING
QFN – RUA
Tape and reel
TS3L500AERUAR
–40°C to 85°C
TQFN – RHU
Tape and reel
TS3L500AERHUR
TK500AE
(1)
Package drawings, thermal data, and symbolization are available at www.ti.com/packaging.
(2)
For the most current package and ordering information, see the Package Option Addendum at the end of this document, or see the TI
website at www.ti.com.
FUNCTION TABLE
INPUT
INPUT/OUTPUT
FUNCTION
SEL
An
L
nB1
An = nB1, LEDx = XLED1
H
nB2
An = nB2, LEDx = XLED2
PIN DESCRIPTION
NAME
DESCRIPTION
An
Data I/Os
nBm
Data I/Os
SEL
Select input
LEDx
LED I/O port
XLEDm
LED I/O port
2
Copyright 2007–2008, Texas Instruments Incorporated
Product Folder Link(s): TS3L500AE
相關PDF資料
PDF描述
TS3USB221RSERG4 1-CHANNEL, DIFFERENTIAL MULTIPLEXER, PQCC10
TS3USB30ERSWR 2-CHANNEL, DIFFERENTIAL MULTIPLEXER, PQCC10
TS3USB30RSWR 1-CHANNEL, DIFFERENTIAL MULTIPLEXER, PQCC10
TS3V712ELRTGR 7-CHANNEL, VIDEO MULTIPLEXER, PQCC32
TS3V712ERTGR 7-CHANNEL, VIDEO MULTIPLEXER, PQCC32
相關代理商/技術參數
參數描述
TS3L500ERHUR 功能描述:電源開關 IC - POE / LAN 16-Bit to 8-Bit SPDT Gigabit LAN Switch RoHS:否 制造商:Fairchild Semiconductor 開關數量:Single 開關配置:SPST 開啟電阻（最大值）:7.3 Ohms 串話: 帶寬: 開啟時間（最大值）:13 ns 關閉時間（最大值）:20 ns 切換電壓（最大）: 工作電源電壓:8 V to 26 V 最大工作溫度:+ 125 C 安裝風格:Through Hole 封裝 / 箱體:TO-220F-6
TS3L500ERHURG4 功能描述:電源開關 IC - POE / LAN 16-Bit to 8-Bit SPDT Gigabit LAN Switch RoHS:否 制造商:Fairchild Semiconductor 開關數量:Single 開關配置:SPST 開啟電阻（最大值）:7.3 Ohms 串話: 帶寬: 開啟時間（最大值）:13 ns 關閉時間（最大值）:20 ns 切換電壓（最大）: 工作電源電壓:8 V to 26 V 最大工作溫度:+ 125 C 安裝風格:Through Hole 封裝 / 箱體:TO-220F-6
TS3L500RHUR 功能描述:電源開關 IC - POE / LAN LAN SWITCH RoHS:否 制造商:Fairchild Semiconductor 開關數量:Single 開關配置:SPST 開啟電阻（最大值）:7.3 Ohms 串話: 帶寬: 開啟時間（最大值）:13 ns 關閉時間（最大值）:20 ns 切換電壓（最大）: 工作電源電壓:8 V to 26 V 最大工作溫度:+ 125 C 安裝風格:Through Hole 封裝 / 箱體:TO-220F-6
TS3L500RHURG4 功能描述:電源開關 IC - POE / LAN 16B-8B SPDT Gigabit LAN Sw RoHS:否 制造商:Fairchild Semiconductor 開關數量:Single 開關配置:SPST 開啟電阻（最大值）:7.3 Ohms 串話: 帶寬: 開啟時間（最大值）:13 ns 關閉時間（最大值）:20 ns 切換電壓（最大）: 工作電源電壓:8 V to 26 V 最大工作溫度:+ 125 C 安裝風格:Through Hole 封裝 / 箱體:TO-220F-6
TS3L501E 制造商:TI 制造商全稱:Texas Instruments 功能描述:16-BIT TO 8-BIT MULTIPLEXER/DEMULTIPLEXER GIGABIT ETHERNET LAN SWITCH WITH POWER DOWN MODE
