ABSOLUTE MAXIMUM RATINGS
DISSIPATION RATINGS
RECOMMENDED OPERATING CONDITIONS
www.ti.com ........................................................................................................................................................................................... SLOS611 – DECEMBER 2008
over operating free-air temperature range (unless otherwise noted)
(1)
VALUE
UNIT
VCC
Supply voltage
AVCC, PVCC
–0.3 to 30
V
Logic input voltage
SD, MUTE, GAIN0, GAIN1
–0.3 to VCC + 0.3
V
Analog input voltage
RIN, LIN
–0.3 to 7
V
Continuous total power dissipation
See Dissipation Rating Table
TA
Operating free-air temperature range
–40 to 85
°C
TJ
Operating junction temperature range
–40 to 150
°C
Tstg
Storage temperature range
–65 to 150
°C
SE Output Configuration
3.2
ZL
Load impedance (minimum value)
BTL Output Configuration
6
Human body model (all pins)
±2
kV
ESD
Electrostatic Discharge
Charged-device model (all
±500
V
pins)
(1)
Stresses beyond those listed under absolute maximum ratings may cause permanent damage to the device. These are stress ratings
only, and functional operation of the device at these or any other conditions beyond those indicated under recommended operating
conditions is not implied. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.
PACKAGE(1)
TA ≤ 25°C
DERATING FACTOR
TA = 70°C
TA = 85°C
20-pin DIP
1.87 W
15 mW/°C
1.20 W
0.97 W
(1)
For the most current package and ordering information, see the Package Option Addendum at the end of this document, or see the TI
website at www.ti.com.
MIN
MAX
UNIT
VCC
Supply voltage
PVCC, AVCC
10
26
V
VIH
High-level input voltage
SD, MUTE, GAIN0, GAIN1
2
V
VIL
Low-level input voltage
SD, MUTE, GAIN0, GAIN1
0.8
V
IIH
High-level input current
SD, MUTE, GAIN0, GAIN1; VIN = VCC = 26 V
125
A
SD, MUTE, GAIN0, GAIN1; VIN = 0, VCC = 26
1
IIL
Low-level input current
A
V
TA
Operating free-air temperature
–40
85
°C
Copyright 2008, Texas Instruments Incorporated
3
Product Folder Link(s): TPA3125D2
