2004 Jul 05
17
Philips Semiconductors
Product specification
12-bit, 5.0 V, 40 Msps analog-to-digital
interface for CCD cameras
TDA9965A
Power and grounding recommendations
Care should be taken to minimize the noise when
designing a printed-circuit board for applications such as
PC cameras, surveillance cameras, camcorders, and
digital still cameras.
For the front-end integrated circuit, the basic rules of
printed-circuit board design and implementation of analog
components (such as classical operational amplifiers)
must be taken into account, particularly with respect to
power and ground connections.
The connections between the CCD interface and the CTH
input should be as short as possible and a ground ring
protection around these connections can be beneficial.
Separate analog and digital supplies provide the best
performance. If it is not possible to do this on the board
then the analog supply pins must be decoupled effectively
from the digital supply pins. The decoupling capacitors
must be placed as close as possible to the IC package.
In a two-ground system, in order to minimize the noise
through the package and die parasitics, the following
recommendation must be implemented:
The ground pin associated with the digital outputs must
be connected to the digital ground plane and special
care should be taken to avoid feedthrough in the analog
ground plane. The analog and digital ground planes
must be connected together with an inductor as closely
as possible to the IC in order for them to have the same
DC voltage.
The digital output pins and their associated lines should
be shielded by the digital ground plane which can then
be used as a return path for the digital signals.
