Philips Semiconductors
TDA8757C
Triple 8-bit ADC 205 Msps
Preliminary data
Rev. 01 — 14 August 2002
10 of 38
9397 750 10111
Koninklijke Philips Electronics N.V. 2002. All rights reserved.
B0G
79
green channel ADC output B bit 0 (LSB)
B1G
80
green channel ADC output B bit 1
B2G
81
green channel ADC output B bit 2
B3G
82
green channel ADC output B bit 3
B4G
83
green channel ADC output B bit 4
B5G
84
green channel ADC output B bit 5
B6G
85
green channel ADC output B bit 6
B7G
86
green channel ADC output B bit 7 (MSB)
OGNDG
87
green channel ADC output B ground
VCCO(G)
88
green channel ADC output B supply voltage
OGNDG
89
green channel ADC output A ground
VCCO(G)
90
green channel ADC output A supply voltage
ORG
91
green channel ADC output bit out of range
A0G
92
green channel ADC output A bit 0 (LSB)
A1G
93
green channel ADC output A bit 1
A2G
94
green channel ADC output A bit 2
A3G
95
green channel ADC output A bit 3
A4G
96
green channel ADC output A bit 4
A5G
97
green channel ADC output A bit 5
A6G
98
green channel ADC output A bit 6
A7G
99
green channel ADC output A bit 7 (MSB)
B0R
100
red channel ADC output B bit 0 (LSB)
B1R
101
red channel ADC output B bit 1
B2R
102
red channel ADC output B bit 2
B3R
103
red channel ADC output B bit 3
B4R
104
red channel ADC output B bit 4
B5R
105
red channel ADC output B bit 5
B6R
106
red channel ADC output B bit 6
B7R
107
red channel ADC output B bit 7 (MSB)
n.c.
108
not connected
OGNDR
109
red channel ADC output B ground
VCCO(R)
110
red channel ADC output B supply voltage
OGNDR
111
red channel ADC output A ground
VCCO(R)
112
red channel ADC output A supply voltage
ORR
113
red channel ADC output A bit out of range
A0R
114
red channel ADC output A bit 0 (LSB)
A1R
115
red channel ADC output A bit 1
A2R
116
red channel ADC output A bit 2
A3R
117
red channel ADC output A bit 3
A4R
118
red channel ADC output A bit 4
A5R
119
red channel ADC output A bit 5
Table 3:
Pin description…continued
Symbol
Pin
Description
