LTC6400-20
4
640020p
AC ELECTRICAL CHARACTERISTICS Specications are at T
A = 25°C. V
+ = 3V, V– = 0V, VOCM = 1.25V,
ENABLE = 0V, No RL unless otherwise noted.
SYMBOL
PARAMETER
CONDITIONS
MIN
TYP
MAX
UNITS
–3dBBW
–3dB Bandwidth
200mVP-P,OUT (Note 6)
1.84
GHz
0.1dBBW
Bandwidth for 0.1dB Flatness
200mVP-P,OUT (Note 6)
0.3
GHz
0.5dBBW
Bandwidth for 0.5dB Flatness
200mVP-P,OUT (Note 6)
0.7
GHz
1/f
1/f Noise Corner
34
kHz
SR
Slew Rate
Differential (Note 6)
4.5
V/ns
tS1%
1% Settling Time
2VP-P,OUT (Note 6)
0.8
ns
tOVDR
Overdrive Recovery Time
1.9VP-P,OUT (Note 6)
4
ns
tON
Turn-On Time
+OUT, –OUT Within 10% of Final Values
220
ns
tOFF
Turn-Off Time
ICC Falls to 10% of Nominal
220
ns
–3dBBWVOCM
VOCM Pin Small Signal –3dB BW
0.1VP-P at VOCM, Measured Single-Ended at
Output (Note 6)
15
MHz
10MHz Input Signal
HD2,10M/HD3,10M
Second/Third Order Harmonic
Distortion
2VP-P,OUT, RL = 400Ω
–97/–93
dBc
2VP-P,OUT, No RL
–98/–97
dBc
2VP-P,OUTFILT, No RL
–100/–98
dBc
IMD3,10M
Third-Order Intermodulation
(f1 = 9.5MHz f2 = 10.5MHz)
2VP-P,OUT Composite, RL = 400Ω
–95
dBc
2VP-P,OUT Composite, No RL
–99
dBc
2VP-P,OUTFILT Composite, No RL
–100
dBc
OIP3,10M
Third-Order Output Intercept Point
(f1 = 9.5MHz f2 = 10.5MHz)
2VP-P,OUT Composite, No RL (Note 7)
53.8
dBm
P1dB,10M
1dB Compression Point
RL = 375Ω (Notes 5, 7)
18
dBm
NF10M
Noise Figure
RL = 375Ω (Note 5)
6.2
dB
eIN,10M
Input Referred Voltage Noise Density
Includes Resistors (Short Inputs)
2.2
nV/√Hz
eON,10M
Output Referred Voltage Noise Density Includes Resistors (Short Inputs)
21.7
nV/√Hz
70MHz Input Signal
HD2,70M/HD3,70M
Second/Third Order Harmonic
Distortion
2VP-P,OUT, RL = 400Ω
–86/–85
dBc
2VP-P,OUT, No RL
–88/–87
dBc
2VP-P,OUTFILT, No RL
–86/–88
dBc
IMD3,70M
Third-Order Intermodulation
(f1 = 69.5MHz f2 = 70.5MHz)
2VP-P,OUT Composite, RL = 400Ω
–93
dBc
2VP-P,OUT Composite, No RL
–94
dBc
2VP-P,OUTFILT Composite, No RL
–93
dBc
OIP3,70M
Third-Order Output Intercept Point
(f1 = 69.5MHz f2 = 70.5MHz)
2VP-P,OUT Composite, No RL (Note 7)
51
dBm
P1dB,70M
1dB Compression Point
RL = 375Ω (Notes 5, 7)
18
dBm
NF70M
Noise Figure
RL = 375Ω (Note 5)
6.2
dB
eIN,70M
Input Referred Voltage Noise Density
Includes Resistors (Short Inputs)
2.1
nV/√Hz
eON,70M
Output Referred Voltage Noise Density Includes Resistors (Short Inputs)
21
nV/√Hz
