Micrel, Inc.
SY69753L
Absolute Maximum Ratings
(1)
Supply Voltage (V
CC
)...................................-0.5V to +5.0V
Input Voltage (V
IN
)...........................................-0.5V to V
CC
Output Current (I
OUT
)
Continuous........................................................±50mA
Surge ..............................................................±100mA
Lead Temperature (soldering, 20sec.)...................+260°C
Storage Temperature (T
s
) ........................-65°C to +150°C
November 2006
4
M9999-111406-D
hbwhelp@micrel.com
or (408) 955-1690
Operating Ratings
(2)
Input Voltage (V
CC
)............................ +3.15V to +3.45V
Ambient Temperature (T
A
)................... –40°C to +85°C
Junction Temperature (T
J
) ................................ +125°C
Package Thermal Resistance
EPAD-TQFP (
θ
JA
)
Still-air....................................................28°C/W
500lfpm..................................................20°C/W
EPAD-TQFP (
θ
JC
)...........................................4°C/W
DC Electrical Characteristics
T
A
= –40°C to +85°C, unless otherwise noted.
Symbol
Parameter
Condition
Min
Typ
Max
Units
V
CC
I
CC
Power Supply Voltage
3.15
3.3
3.45
V
Power Supply Current
170
230
mA
PECL 100K DC Electrical Characteristics
V
CC
= V
CCO
= V
CCA
= 3.3V ±5%; T
A
= –40°C to +85°C, unless otherwise noted.
Symbol
Parameter
Condition
Min
Typ
Max
Units
V
IH
V
IL
V
OH
V
OL
I
IL
Input HIGH Voltage
V
CC
-1.165
V
CC
-1.810
V
CC
-1.075
V
CC
-1.860
0.5
V
CC
-0.880
V
CC
-1.475
V
CC
-0.830
V
CC
-1.570
V
Input LOW Voltage
V
Output HIGH Voltage
50
to V
CC
-2V
50
to V
CC
-2V
V
IN
= V
IL
(Min)
V
Output LOW Voltage
V
Input LOW Current
μA
TTL DC Electrical Characteristics
V
CC
= V
CCO
= V
CCA
= 3.3V ±5%; T
A
= –40°C to +85°C, unless otherwise noted.
Symbol
Parameter
Condition
Min
Typ
Max
Units
V
IH
V
IL
V
OH
V
OL
I
IH
Input HIGH Voltage
2.0
V
CC
0.8
V
Input LOW Voltage
V
Output HIGH Voltage
I
OH
= -0.4mA
I
OL
= 4mA
V
IN
= 2.7V, V
CC
= Max.
V
IN
= V
CC
, V
CC
= Max.
V
IN
= 0.5V, V
CC
= Max.
V
OUT
= 0V, (max., 1 sec.)
2.0
V
Output LOW Voltage
0.5
V
Input HIGH Current
-125
+100
μA
μA
I
IL
I
OS
Input LOW Voltage
-300
μA
Output Short Circuit Current
-15
-100
mA
Notes:
1. Permanent device damage may occur if absolute maximum ratings are exceeded. This is a stress rating only and functional operation is not
implied at conditions other than those detailed in the operational sections of this data sheet. Exposure to absolute maximum rating conditions for
extended periods may affect device reliability.
2. The data sheet limits are not guaranteed if the device is operated beyond the operating ratings.
3. Numbers valid with proper thermal design of PCB and exposed pad soldered to island on PCB. Refer to Figure on page 13.
