參數資料
| 型號： | SY56017RMG |
| 廠商： | Micrel Inc |
| 文件頁數： | 4/4頁 |
| 文件大?。?/td> | 0K |
| 描述： | IC CLOCK MUX 2:1 4.5GHZ 16-MLF |
| 標準包裝： | 100 |
| 系列： | Precision Edge® |
| 類型： | 多路復用器 |
| 電路數： | 1 |
| 比率 - 輸入:輸出： | 2:1 |
| 差分 - 輸入:輸出： | 是/是 |
| 輸入： | CML，LVDS，LVPECL |
| 輸出： | CML |
| 頻率 - 最大： | 4.5GHz |
| 電源電壓： | 2.375 V ~ 2.625 V |
| 工作溫度： | -40°C ~ 85°C |
| 安裝類型： | 表面貼裝 |
| 封裝/外殼： | 16-VFQFN 裸露焊盤，16-MLF? |
| 供應商設備封裝： | 16-MLF?（3x3） |
| 包裝： | 管件 |
| 產品目錄頁面： | 1089 (CN2011-ZH PDF) |
| 其它名稱： | 576-3289-5 |
Micrel, Inc.
SY56017R
July 2008
4
M9999-070308-A
hbwhelp@micrel.com or (408) 955-1690
Absolute Maximum Ratings
(1)
Supply Voltage (VCC) ............................... –0.5V to +3.0V
Supply Voltage (VCCO) ............................. –0.5V to +3.0V
VCC - VCCO ...............................................................<1.8V
VCCO - VCC ...............................................................<0.5V
Input Voltage (VIN) .......................................–0.5V to VCC
CML Output Voltage (VOUT) ......................... 0.6V to 3.0V
Current (VT)
Source or sink on VT pin .............................±100mA
Input Current
Source or sink Current on (IN, /IN) ................±50mA
Maximum operating Junction Temperature .......... 125°C
Lead Temperature (soldering, 20sec.) .................. 260°C
Storage Temperature (Ts) ....................–65°C to +150°C
Operating Ratings
(2)
Supply Voltage (VCC) ..........................2.375V to 2.625V
(VCCO)……………..……1.14V to
2.625V
Ambient Temperature (TA) ................... –40°C to +85°C
Package Thermal Resistance
(3)
QFN
Still-air (
θ
JA) ............................................ 75°C/W
Junction-to-board (
ψ
JB) ......................... 33°C/W
DC Electrical Characteristics
(4)
TA = –40°C to +85°C, unless otherwise stated.
Symbol
Parameter
Condition
Min
Typ
Max
Units
VCC
Power Supply Voltage Range
VCC
VCCO
2.375
1.14
1.7
2.375
2.5
1.2
1.8
2.5
2.625
1.26
1.9
2.625
V
ICC
Power Supply Current
Max. VCC
55
80
mA
ICCO
Power Supply Current
No Load. VCCO
16
21
mA
RIN
Input Resistance
(IN-to-VT, /IN-to-VT )
45
50
55
RDIFF_IN
Differential Input Resistance
(IN-to-/IN)
90
100
110
VIH
Input HIGH Voltage
(IN, /IN)
IN, /IN
1.42
VCC
V
VIL
Input LOW Voltage
(IN, /IN)
IN, /IN
1.22V = 1.7-0.475
1.22
VIH–0.2
V
VIN
Input Voltage Swing
(IN, /IN)
see Figure 3a, Note 5, applied to
input of transmission line.
0.2
1.0
V
VDIFF_IN
Differential Input Voltage Swing
(|IN - /IN|)
see Figure 3b, Note 5, applied to
input of transmission line.
0.4
2.0
V
VT_IN
Voltage from Input to VT
1.28
V
Notes:
1. Permanent device damage may occur if absolute maximum ratings are exceeded. This is a stress rating only and functional operation is not
implied at conditions other than those detailed in the operational sections of this data sheet. Exposure to absolute maximum ratings conditions for
extended periods may affect device reliability.
2. The data sheet limits are not guaranteed if the device is operated beyond the operating ratings.
3. Package thermal resistance assumes exposed pad is soldered (or equivalent) to the device's most negative potential on the PCB.
ψ
JB and θJA
values are determined for a 4-layer board in still-air number, unless otherwise stated.
4. The circuit is designed to meet the DC specifications shown in the above table after thermal equilibrium has been established.
5. VIN(max) is specified when VT is floating.
