PACKAGE MECHANICAL DATA
TO-247
F2
F1
V2
L4
L2
L1
L3
D
L
L5
ME
H
V
A
Dia.
F3
F4
G
=
F(x3)
REF.
DIMENSIONS
Millimeters
Inches
Min.
Typ.
Max.
Min.
Typ.
Max.
A
4.85
5.15 0.191
0.203
D
2.20
2.60 0.086
0.102
E
0.40
0.80 0.015
0.031
F
1.00
1.40 0.039
0.055
F1
3.00
0.118
F2
2.00
0.078
F3
2.00
2.40 0.078
0.094
F4
3.00
3.40 0.118
0.133
G
10.90
0.429
H
15.45
15.75 0.608
0.620
L
19.85
20.15 0.781
0.793
L1
3.70
4.30 0.145
0.169
L2
18.50
0.728
L3
14.20
14.80 0.559
0.582
L4
34.60
1.362
L5
5.50
0.216
M
2.00
3.00 0.078
0.118
V5°
5°
V2
60°
Dia.
3.55
3.65 0.139
0.143
Ordering code
Marking
Package
Weight
Base qty
Delivery mode
STTH6006TV1
STTH6006TV
ISOTOP
27g
without screws
10
with screws
Tube
STTH6006CW
TO-247
4.36g
30
Tube
Cooling method: by conduction (C)
Recommended torque value (ISOTOP): 1.3 N.m.
Recommended torque value (TO-247°: 0.8 N.m.
Maximum torque value (ISOTOP): 1.5 N.m.
Maximum torque value (TO-247): 1.0 N.m.
Epoxy meets UL 94,V0
STTH6003TV/CW
6/6
