參數資料
| 型號： | SHD119445P |
| 廠商： | SENSITRON SEMICONDUCTOR |
| 元件分類： | 整流器 |
| 英文描述： | 35 A, SILICON, RECTIFIER DIODE |
| 封裝： | HERMETIC SEALED, LCC-3 |
| 文件頁數： | 1/3頁 |
| 文件大?。?/td> | 36K |
| 代理商： | SHD119445P |
221 WEST INDUSTRY COURT DEER PARK, NY 11729-4681 PHONE (631) 586-7600 FAX (631) 242-9798
World Wide Web - http://www.sensitron.com E-Mail - sales@sensitron.com
SENSITRON
SEMICONDUCTOR
TECHNICAL DATA
DATA SHEET 5099, REV. A
HERMETIC POWER SCHOTTKY RECTIFIER
(SINGLE / DUAL)
DESCRIPTION: A 150 VOLT, 30 AMP, POWER SCHOTTKY RECTIFIER IN A HERMETIC LCC-3P PACKAGE.
MAXIMUM RATINGS
ALL RATINGS ARE @ TC = 25 °C UNLESS OTHERWISE SPECIFIED.
RATING
SYMBOL
MAX.
UNITS
PEAK INVERSE VOLTAGE
PIV
150
Volts
MAXIMUM DC OUTPUT CURRENT With Cathode Maintained (@ TC=100
OC)
(Single)
IO
30
Amps
MAXIMUM DC OUTPUT CURRENT With Cathode Maintained (@ TC=100
OC)
(Common Cathode)
IO
35
Amps
MAXIMUM NONREPETITIVE FORWARD SURGE CURRENT
(t = 8.3ms, Sine)
IFSM
150
Amps
MAXIMUM JUNCTION CAPACITANCE
(Vr =5V)
CT
1000
pF
MAXIMUM THERMAL RESISTANCE Single
RθJC
1.25
°C/W
MAXIMUM THERMAL RESISTANCE Common Cathode
RθJC
0.63
°C/W
MAXIMUM OPERATING AND STORAGE TEMPERATURE RANGE
Top/Tstg
-65 to
+ 200
°C
ELECTRICAL CHARACTERISTICS
CHARACTERISTIC
MAXIMUM FORWARD VOLTAGE DROP, Pulsed (If = 35 Amps)
TJ = 25 °C
TJ = 125 °C
Vf
1.05
0.89
Volts
MAXIMUM REVERSE CURRENT (Ir @ 150 V PIV)
TJ = 25 °C
TJ = 125 °C
Ir
1.5
24
mA
SHD119445
SHD119445P
相關PDF資料 |
PDF描述 |
|---|---|
| SHD119445 | 30 A, SILICON, RECTIFIER DIODE |
| SHD119834 | 60 A, SILICON, RECTIFIER DIODE |
| SHD122511D | SILICON, RECTIFIER DIODE |
| SHD122511P | SILICON, RECTIFIER DIODE |
| SHD124636D | SILICON, RECTIFIER DIODE, TO-258AA |
相關代理商/技術參數 |
參數描述 |
|---|---|
| SHD119446 | 制造商:SENSITRON 制造商全稱:Sensitron 功能描述:HERMETIC POWER SCHOTTKY RECTIFIER |
| SHD119468 | 制造商:SENSITRON 制造商全稱:Sensitron 功能描述:HERMETIC POWER SCHOTTKY RECTIFIER |
| SHD119511 | 制造商:SENSITRON 制造商全稱:Sensitron 功能描述:HERMETIC POWER SCHOTTKY RECTIFIER |
| SHD119512 | 制造商:SENSITRON 制造商全稱:Sensitron 功能描述:HERMETIC POWER SCHOTTKY RECTIFIER Very Low Forward Voltage Drop |
| SHD119512_11 | 制造商:SENSITRON 制造商全稱:Sensitron 功能描述:HERMETIC POWER SCHOTTKY RECTIFIER Very Low Forward Voltage Drop |
