Connection Diagrams
20071403
LLP Top View
DAP = GND
20071404
LQFP Top View
Configuration Select Truth Table
SEL0
0
0
1
1
0
1
0
0
X
0
1
1
1
PD = Power Down mode to minimize power consumption
X = Don’t Care
* Entering these states is not forbidden, however device operation is not defined in these states.
SEL1
0
1
0
1
1
1
0
1
X
0
0
0
1
EN0
0
0
0
0
0
0
1
1
1
0
0
1
1
EN1
0
0
0
0
1
1
0
0
1
1
1
0
0
OUT0
IN0
IN0
IN1
IN1
IN0
IN1
PD
PD
PD
OUT1
IN0
IN1
IN0
IN1
PD
PD
IN0
IN1
PD
Mode
1:2 Splitter (IN1 powered down)
Dual Channel Repeater
Dual Channel Switch
1:2 Splitter (IN0 powered down)
Single Channel Repeater (Channel 1 powered down)
Single Channel Switch (IN0 and OUT1 powered down)
Single Channel Switch (IN1 and OUT0 powered down)
Single Channel Repeater (Channel 0 powered down)
Both Channels in Power Down Mode
Invalid State*
Invalid State*
Invalid State*
Invalid State*
Pre-emphasis
The pre-emphasis is used to compensate for long or lossy
transmission media. Separate pins are provided for each
output to minimize power consumption. Pre-emphasis is
programmable to be off or to preset values per the Pre-
emphasis Control Selection Table.
Output Characteristics
The output characteristics of the SCAN90CP02 device have
been optimized for point-to-point backplane and cable appli-
cations.
Pre-emphasis Control Selection Table
Channel 0
PEM01
0
0
1
1
Channel 1
PEM11
0
0
1
1
Pre-emphasis
PEM00
0
1
0
1
PEM10
0
1
0
1
0%
25%
50%
100%
S
www.national.com
3
