Silan
Semiconductors
SC2128C
HANGZHOU SILAN MICROELECTRONICS JOINT-STOCK CO.,LTD
Rev: 1.1 2001.09.26
7
* Four LEDs (Tb0, Tb1, Tb2, Tb3) are used to indicate the off-timer period. Depending on the base timer step
option, timer step may be 0.5 hour or 1 hour as indicated in the diagram.
If SC2128C is selected with 4 hour timer
option
If SC2128C is selected with 8 hour timer
option
Tb0=0.5 hour
b1=1 hour
b2=2 hour
b3=4 hour
Tb0=1 hour
b1=2 hour
b2=4 hour
b3=8 hour
The time schedule is the sum of all ON LEDs. For example, if SC2128C is programmed with 1/2/4/8 hour
accumulated timer option, and is Tb0 is ON, Tb1 is OFF, Tb2 is OFF, Tb3 is ON, then the schedule period is 9
hours (1 hr + 9 hr).
* Rhythm LED , Sleep LED and Ordinary LED indicate SC2128C operation modes.
Operation mode
Rhythm LED
Sleep LED
Ordinary LED
ORD (ordinary wind)
OFF
OFF
ON
RTM (rhythm wind)
ON
OFF
OFF
RSL (rhythm sleep wind)
OFF
ON
OFF
* Three LEDs – Low, Middle and Strong – are used to indicate the respective output status of LO, MI, ST output.
LED being ON indicates output active (L). LED being OFF indicates output inactive (Z). Only one output among
LO, MI and HI may be active at a specific time.
* Swing1 LED, Swing2 LED and Light LED indicated respective output status of SO1, SO2, and LIT.
9. TIMER
The external timer of SC2128C may be bonding optioned
into six (6) configurations as shown. Each pressing of
TIMER key will step the internal timer one step up. The
actual sequence depends on the TIMER option selected.
The following diagrams show the timer sequence for each
TIMER option. TIMER automatically counts down as time
passes by. The count down sequence reverses the key
sequence and is also shown in the following diagrams.
: 0.5, 1, 2, 4 hours non-accumulated
: 1, 2, 4, 8 hours non-accumulated
: 0.5, 1, 2, 4 hours accumulated
: 1, 2, 4, 8 hours accumulated
: 1, 2, 4 hours non-accumulated
: 1, 2, 4 hours accumulated
