Philips Semiconductors
SC16C2550B
5 V, 3.3 V and 2.5 V dual UART, 5 Mbit/s (max.), with 16-byte FIFOs
Product data
Rev. 02 — 14 December 2004
11 of 42
9397 750 14449
Koninklijke Philips Electronics N.V. 2004. All rights reserved.
6.3 FIFO operation
The 16 byte transmit and receive data FIFOs are enabled by the FIFO Control
Register (FCR) bit 0. The user can set the receive trigger level via FCR bits 6-7, but
not the transmit trigger level. The receiver FIFO section includes a time-out function
to ensure data is delivered to the external CPU. An interrupt is generated whenever
the Receive Holding Register (RHR) has not been read following the loading of a
character or the receive trigger level has not been reached.
6.4 Hardware/software and time-out interrupts
The interrupts are enabled by IER[0-3]. Care must be taken when handling these
interrupts. Following a reset, if Interrupt Enable Register (IER) bit 1 = 1, the
SC16C2550B will issue a Transmit Holding Register interrupt. This interrupt must be
serviced prior to continuing operations. The ISR register provides the current singular
highest priority interrupt only. A condition can exist where a higher priority interrupt
may mask the lower priority interrupt(s). Only after servicing the higher pending
interrupt will the lower priority interrupt(s) be reflected in the status register. Servicing
the interrupt without investigating further interrupt conditions can result in data errors.
When two interrupt conditions have the same priority, it is important to service these
interrupts correctly. Receive Data Ready and Receive Time Out have the same
interrupt priority (when enabled by IER[0]). The receiver issues an interrupt after the
number of characters have reached the programmed trigger level. In this case, the
SC16C2550B FIFO may hold more characters than the programmed trigger level.
Following the removal of a data byte, the user should re-check LSR[0] for additional
characters. A Receive Time Out will not occur if the receive FIFO is empty. The
time-out counter is reset at the center of each stop bit received or each time the
receive holding register (RHR) is read. The actual time-out value is 4 character time,
including data information length, start bit, parity bit, and the size of stop bit, i.e., 1
×
,
1.5
×
, or 2
×
bit times.
Table 5:
Selected trigger level (characters)
1
4
8
14
Flow control mechanism
INT pin activation
1
4
8
14
