BATTERY PROTECTION IC FOR 3-SERIES OR 4-SERIES CELL PACK
S-8204A Series
Rev.1.5_00
Seiko Instruments Inc.
18
10. SEL pin
The S-8204A Series has a pin to switch-control the protection for 3-cell or 4-cell battery. The
overdischarge detection for V4-cell is inhibited by setting the SEL pin “L”, so that short-circuiting the V4
cell does not allow the overdischarge detection. This setting makes it possible to use the S-8204A Series
for 3-cell protection. The SEL pin precedes the battery protection circuit. Be sure to use the SEL pin in “H”
or “L”.
Table 7 Protect Conditions Set by SEL Pin
SEL Pin
Condition
High
*1
4-cell protection
Open
Indefinite
Low
*2
3-cell protection
*1. High; SEL
≥ VSELH
*2. Low; SEL
≤ VSELL
In cascade connection, it is possible to use the S-8204A Series for protecting 6, 7 or 8-cell battery by
combining the electrical level of SEL pin.
Table 8 Conditions Set by SEL Pin in Cascade Connection
SEL pin in S-8204B (1)
SEL pin in S-8204B (2)
Condition
Low
*1
Low
*1
6-series cell protection
Low
*1
High
*2
7-series cell protection
High
*2
High
*2
8-series cell protection
*1. Low; SEL
≤ VSELL
*2. High; SEL
≥ VSELH
