RTL8309SB
Datasheet
Single-chip 9-port 10/100Mbps Switch Controller
25
Track ID: JATR-1076-21 Rev. 1.4
6.2.12. IP Mask
Table 28. IP Mask
Name
Byte.bit Description
Default
IP Mask [A]
IP Mask [A]
[16:23]
32.7~
32.0
If IP priority for IP address [A] is enabled, the switch will compare the
source IP address of an incoming packet against the value, IP address [A]
AND IP mask [A], to classify priority for the packet.
IP Mask [A]
If IP priority for IP address [A] is enabled, the switch will compare the
source IP address of an incoming packet against the value, IP address [A]
AND IP mask [A], to classify priority for the packet.
IP Mask [A]
If IP priority for IP address [A] is enabled, the switch will compare the
source IP address of an incoming packet against the value, IP address [A]
AND IP mask [A], to classify priority for the packet.
IP Mask [A]
If IP priority for IP address [A] is enabled, the switch will compare the
source IP address of an incoming packet against the value, IP address [A]
AND IP mask [A], to classify priority for the packet.
IP Mask [B]
If IP priority for IP address [B] is enabled, the switch will compare the
source IP address of an incoming packet against the value, IP address [B]
AND IP mask [B], to classify priority for the packet.
IP Mask [B]
If IP priority for IP address [B] is enabled, the switch will compare the
source IP address of an incoming packet against the value, IP address [B]
AND IP mask [B], to classify priority for the packet.
IP Mask [B]
If IP priority for IP address [B] is enabled, the switch will compare the
source IP address of an incoming packet against the value, IP address [B]
AND IP mask [B], to classify priority for the packet.
IP Mask [B]
If IP priority for IP address [B] is enabled, the switch will compare the
source IP address of an incoming packet against the value, IP address [B]
AND IP mask [B], to classify priority for the packet.
0xff
IP Mask [A]
[31:24]
33.7~
33.0
0xff
IP Mask [A]
[7:0]
34.7~
34.0
0xff
IP Mask [A]
[15:8]
35.7~
35.0
0xff
IP Mask [B]
[16:23]
36.7~
36.0
0xff
IP Mask [B]
[31:24]
37.7~
37.0
0xff
IP Mask [B]
[7:0]
38.7~
38.0
0xff
IP Mask [B]
[15:8]
39.7~
39.0
0xff
6.2.13. Port 2 Control 0
Table 29. Port 2 Control 0
Name
Reserved
Byte.bit Description
40.7
~40.6
40.5~
40.4
11=MII Reg0.13=1, 0.8=1, 4.8=1, 4.7=1, 4.6=1, 4.5=1
10=MII Reg0.13=1, 0.8=0, 4.8=0, 4.7=1, 4.6=1, 4.5=1
01=MII Reg0.13=0, 0.8=1, 4.8=0, 4.7=0, 4.6=1, 4.5=1
00=MII Reg0.13=0, 0.8=0, 4.8=0, 4.7=0, 4.6=0, 4.5=1
In Force mode:
11=MII Reg0.13=1, 0.8=1, 4.8=1, 4.7=0, 4.6=0, 4.5=0
10=MII Reg0.13=1, 0.8=0, 4.8=0, 4.7=1, 4.6=0, 4.5=0
01=MII Reg0.13=0, 0.8=1, 4.8=0, 4.7=0, 4.6=1, 4.5=0
00=MII Reg0.13=0, 0.8=0, 4.8=0, 4.7=0, 4.6=0, 4.5=1
Default
11
Speed and
Duplex ability
In auto negotiation mode:
11
